DU-HA 20110 Installation Instructions

2015 - 2019 Ford F-150 SuperCrew &
2017 - 2019 Ford F-250 to F-550 Super Duty SuperCrew
Underseat Storage
Installation Instructions:
F-150 SuperCrew
1
Flip up the seat bottoms of the back seats.
2
Using an 8mm socket remove the top two bolts from the factory storage divider (as
shown by arrows in picture 1). Note: Some models do not have the factory divider or
bolts. Refer to following page on how to create threads so you can use the knobs for
installation. Note: Some F-250 to F-550 models have a factory storage tray on the floor.
This will need to be removed to install the DU-HA, follow the instructions on next page for
removal. Some trucks have a vinyl floor which makes the DU-HA sit lower see following
page for further instructions.
3
Position the DU-HA (A) under the back seat with the cut out slots in the DU-HA facing
towards the truck bed.
4
Secure the DU-HA (A) in the truck using the knobs (D), insert the knob through the slot in
the back of the DU-HA and thread into the holes from the previously removed bolts.
5
Install the (B) Foam Organizer / Gun Rack and (C) Plastic Stiffeners by sliding them into
the channel slots inside the DU-HA, making sure the high side faces towards the front
(as pictured).
Pull the lever under each back seat to return the seat bottoms to the down position.
Please note: When the seat is down, it does not latch. The seat is designed to latch only when it is up.
(To test this, you may put the seat down without the DU-HA underneath. Note that it does not latch down.)

Safety Instructions:

Warning: Seat bottoms must be down at all times while
vehicle is moving. Make sure the DU-HA is secured in the
vehicle according to installation instructions. Do not store
explosives or hazardous materials in the DU-HA.
Do not place loaded guns in the DU-HA.
For further instructions refer to truck owners
manual or contact DU-HA, Inc.
Part Description
A DU-HA Storage Unit
B Foam Organizer / Gun Rack
C Plastic Stiffener
D Knob
E Nut – M6
F Washer – M6
G Bolt M6 - Taptite
DU-HA, Inc. // website: www.du-ha.com
Qty
1
2
4
2
2
2
1
// phone: 1.866.306.DUHA (3842) //
Installation Instructions
Factory Divider
B
C
A
fax: 1.218.998.4013 // 306 Saint Andrews Street South, Fergus Falls, MN 56537
DIVIDER – 20110
Fits DU-HA Part Numbers
20110 20210
20111
20211
20112
20212
20113
20213
1
3
4
5
E
D
This is how the DU-HA should look
F
installed under the back seat.
Rev-D
