Summary of Contents for Clarke PRO238
- Page 1 DIGITAL TORQUE ADAPTOR Model No: PRO238 PART NO: 1700638 OPERATING & MAINTENANCE INSTRUCTIONS GC12/16...
-
Page 2: Environmental Protection
INTRODUCTION Thank you for purchasing this CLARKE Torque Adaptor. This CLARKE product has been designed to give long and trouble free service. If however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. -
Page 3: Specifications
0-40 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 4: The Control Panel
THE CONTROL PANEL THE DISPLAY A Peak/Track mode indicator B The value of torque measured/preset value displayed C Selectable units of measurement D Battery Condition indicator THE PUSHBUTTONS 1. Power ON/OFF button. 2. Warning LED illuminates when the pre-set torque is reached. Zero/tare. -
Page 5: Preparation For Use
PREPARATION FOR USE FITTING THE BATTERIES 1. Remove the screw securing the battery cover to the back of the unit and lift off the cover. 2. Install batteries (2 x CR2032 as supplied) with their marked faces to the right, and refit the cover. •... -
Page 6: Operation
HOW TO SELECT TORQUE SETTING 1. With the unit of measurement already chosen, press the will flash briefly) and the torque value will be displayed with the first digit flashing. • The value will display for 3 seconds then revert to 0.0, i.e., step 2 must be commenced within 3 seconds. -
Page 7: Storage And Cleaning
The adaptor has been calibrated at the factory in order to ensure accurate readings and should not require any re-calibration. The original calibration certificate should be supplied. If inaccuracy is suspected, contact your local Clarke dealer. To maintain the accuracy of the adaptor periodically reset by holding the buttons together.
