NOTICE Please retain these instructions for future reference. • Please read the manual carefully before beginning to exercise. • Firmly secure all screws before use. • Product is intended for indoor use only. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 3
HARDWARE M8 SPRING M8 LARGE M8 WASHER WASHER WASHER 4 PCS 4 PCS 4 PCS PARTS SEAT FRAME REAR BOTTOM REAR FRAME SEAT CUSHION TUBE 1 PC 1 PC 1 PC 1 PC FIXING PLATE BACKREST HANDLEBAR FRONT BOTTOM CUSHION TUBE 1 PC 1 PC...
PRODUCT ASSEMBLY Attach part A rear bottom tube to part B rear frame with two part 1 bolt sets. Attach part C seat frame to the rear frame with four part 4 screws, four part 5 spring washers, and four part 7 washers.
Page 5
PRODUCT ASSEMBLY Remove the screws from the part D seat cushion. Replace the screws to attach the seat cushion to the seat frame. Remove the screws from the part E backrest cushion. Replace the screws to attach the backrest cushions to the seat frame.
Page 6
PRODUCT ASSEMBLY Attach part F handlebar with the part G fixing plate and two part 3 bolt sets. Join the two connectors on the handlebar to the corresponding connectors on the frame. HEART RATE MONITOR Place hands on the heart rate grips during your workout to monitor your pulse in BPM (beats per minute).
Page 7
PRODUCT ASSEMBLY Attach part H front bottom tube to part I front frame with two part 1 bolt sets. Use the multifunction tool to install the part J pedal set (L/R). NOTE: The left pedal must be screwed counter-clockwise and the right pedal must be screwed clockwise.
Page 8
PRODUCT ASSEMBLY Join the three connectors and metal wire on the front frame to the corresponding connectors/wire on the part K support tube. Attach the support tube with four part 4 screws and four part 6 large washers. Attach the metal wire to the corresponding wire by hooking the head into the designated slot, then sliding the wire into the bracket to secure it (make sure wire is straight).
Page 9
PRODUCT ASSEMBLY Attach part L front handlebar with two part 2 bolt sets. Install two AAA batteries in the part M display monitor. Join the three connectors on the display monitor to the corresponding connectors on the top of the support tube. Remove screws from the display monitor, then replace the screws to attach the display monitor to the support tube.
PRODUCT ASSEMBLY Join the two connectors on the front frame to the corresponding connectors on the rear frame. Slide the rear frame into the front frame and tighten the adjustment knob to your desired frame length. TENSION ADJUSTMENT • Before beginning your workout, adjust the tension to your desired level.
DISPLAY MONITOR • Monitor turns on when the mode button is pressed or when pedals spin. • Monitor turns o automatically after 4 minutes of non-use. Mode Button: Press to select a function to display. • Press and hold for 3 seconds to reset. •...
