Westward 24A482 Operating Instructions And Manual

Operating Instructions and Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Description
The Electric Engraver is designed to easily engrave in various materials with its cemented carbide grinding tips. The
compact and ergonomic design is comfortable to use and the rocker switch provides easy operation.
Unpacking
After unpacking unit, inspect carefully
for any damage that may have
occurred during transit. Check for
loose, missing, or damaged parts.
Shipping damage claim must be filed
with carrier.
Certification
3042597
This symbol designates that this tool
is listed with U.S. requirements by
ETL Testing Laboratories, Inc.
Conforms to UL Std. 60745-1.
Certified to CAN/CSA STD C22.2 No.60745-1.
Specifications and Dimensions
Amperes
Model (A)
21A482 0.2
General Safety Information
Read and understand all
instructions. Failure to follow all instructions
listed below may result in electric shock, fire,
and/or serious personal injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to mains-
operated (corded) power tool or battery-operated
(cordless) power tool.
WORK AREA SAFETY
Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
FORM JGD482
Stroke per minute
(SPM) Length
3600 8
Printed in China
04634
Version 0
Electric Engraver
Dimensions (Inches)
Width Height
2 2-1/8
Do not operate power tools in potentially
explosive environments, such as in the presence
of flammable liquids, gas, or dust. Power tools
create sparks that may ignite dust or fumes.
Keep bystanders, children, and visitors away
while operating the tool. Distractions can cause the
operator to lose control.
ELECTRICAL SAFETY
Double insulated tools are equipped with a
polarized plug (one blade is wider than the other).
This plug will only fit into a polarized plug one way.
If the plug does not fit into the outlet properly,
reverse the plug. If it still does not fit, contact a
qualified electrician to install a polarized outlet. Do not
alter the plug in any way. Double insulation eliminates
the need for the three-pronged grounded power cord
and grounded power supply system.
24A482
Weight
(Lbs)
0.84
06/12
