Olivon T-64 Instruction Manual

Hide thumbs
1
2

Advertisement

Table of Contents

PARTS DIAGRAM
Zoom
Ring
Rubber
Eyecup
Focus Knob
Eyepiece
Locking Ring
Mounting
Shoe

SPECIFICATIONS

Spotting Scope:
- 65mm objective
- angled or straight eyepiece setting
- field at 1000m: 43-22m
- aperture field: 30-43 degrees
- exit pupil: 4.1-1.4mm
- eye relief: 18-15mm
- focal length of scope: 386mm
- focal length of eyepiece: 8-24mm
- magnification: 16-48x
- multi-coated lens
- water proof, fog proof
- stay-on carrying bag
Spotting Scope Instruction Guide
Sun Shade
Dust Cap
Olivon T-64
*Illustrations may differ slightly from the actual scope.
2011/07/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-64 and is the answer not in the manual?

Questions and answers

Related Manuals for Olivon T-64

Summary of Contents for Olivon T-64

  • Page 1 Olivon T-64 PARTS DIAGRAM Zoom Ring Rubber Spotting Scope Instruction Guide Eyecup Focus Knob Sun Shade Eyepiece Locking Ring Dust Cap Mounting Shoe SPECIFICATIONS Spotting Scope: - 65mm objective - angled or straight eyepiece setting - field at 1000m: 43-22m - aperture field: 30-43 degrees - exit pupil: 4.1-1.4mm...
  • Page 2 USING THE SPOTTING SCOPE *Illustrations may differ slightly from actual product. A) Using the Rubber Eyecup The zoom eyepiece includes a soft rubber eyecup for eyeglass wearers. Fold down the rubber eyecup to observe the full apparent field of view with eyeglasses on. B) Focusing Adjust the eyepiece so it’s at the lowest zoom power first.
