Installation instructions for JK-19536, PRO-Series Stubby Front Winch Bumper
Fits 2007- Current Jeep Wrangler JK, all models
** Inspect bumper prior to installation.
** Due to the weight of the bumper it is recommended at least two people for installation
Hardware List:
10MM-30MM Shoulder Hex Head Bolt Qty: 12
10MM-40MM shoulder Hex Head Bolt Qty: 4
10MM Flat washer Qty: 12
10MM Shoulder Nut Qty: 16
1/4"-5/8" Round Head Allen Drive Bolt Qty: 6
1/4"-1/2" Hex Head Bolt Qty: 2
1/4" Nylock Hex Nuts Qty: 6
Silver Flat Plate With threaded nut Qty: 2
Plastic Tube Plugs Qty: 5
Logo Plate Qty: 1
Winch Fare lead Mounting Bracket
Accessories: (sold separately)
JK-19536-WC (Bumper wing kit, cube LED)
JK-19536-WCC (Bumper wing KIT, w lights)
JK-19536-WR (Bumper wing kit, OEM light)
50018 (BA 18" single row LED kit)
30033 (BA Cube LED kit Spot)
30034 (BA Cube LED kit fog)
INSTALLATION INSTRUCTIONS
Made in the USA
Advertisement
Table of Contents
Summary of Contents for Body Armor 4x4 PRO-Series
- Page 1 INSTALLATION INSTRUCTIONS Installation instructions for JK-19536, PRO-Series Stubby Front Winch Bumper Fits 2007- Current Jeep Wrangler JK, all models Made in the USA ** Inspect bumper prior to installation. ** Due to the weight of the bumper it is recommended at least two people for installation...
- Page 2 INSTALLATION INSTRUCTIONS Removing Bumper: Step 1 Remove the (2) push-pin screws to remove the plastic frame cover-plate. Step 2 If equipped, disconnect the OE driving lights at the back of the light housings. Insulate ends and tie the wires to the frame. Do not cut ends. Step 3 Using appropriate tools, remove the OE front bumper by removing the hex nuts holding the bumper to frame mount flanges.
- Page 3 INSTALLATION INSTRUCTIONS Step 2 On the bottom of the bumper where the plate goes under the crash bar you will attach the bumper to the crash bar by using 10M-40M hex bolts. The available holes in the crash bar can vary based on the year of the vehicle. You should be able to line up the holes and attach. There could be a gap between the lip of the bumper and the crash bar.
