TECHLIGHTING 700DJTELC Installation Instructions

Telescopes from 9 to 25 inches and pivots at head to direct beam.

Advertisement

Quick Links

Installation Instructions for
DJ-Telescope
DISPLAY JACK
GENERAL PRODUCT INFORMATION:
This product is suitable for indoor dry locations only.
Wild Thing, Sun Louver, Flight Paper, MR16 Snout, Round
Glass Shield, Lil Egypt, Lil Wok, Barndoors, Snap Barndoors,
Backlight Shield, Louver Lend Holder, Snap Louver Holder,
Eggcrate Louver, and Glass Lens are the compatible
accessories and optical controls.
Installing the Lamp
1A
LAMP PIN
1
CAUTION: To reduce the risk of a burn or electric
shock during relamping, disconnect the power to
the fixture.
NOTE:
Use only your fingers and a soft cloth to
replace the lamp.
Use MAX 75 Watt, MR16 Front Cover Halogen
Lamp.
Push the MR16 lamp pins all the way into the socket
1
pins.
SOCKET PIN
1
1E
1B
LAMP HOLDER
SPRING
2
HOOK IT HERE
Hook one end of the lamp holder spring (provided with
2
the package) onto front of the lamp. Wrap the spring
over the slot in the middle of the socket and hook the
other end onto front of the lamp.
920DJTELE
700DJTELC
SLOT IN THE MIDDLE
OF THE SOCKET
MR16 LAMP
2
HOOK IT HERE
1.6
