Gryphon Dynamics GD-8 Assembly & Instruction Manual

Designed for professional frames
Hide thumbs

Advertisement

Quick Links

Download this manual
Rev. Nov 2013
GRYPHON DYNAMICS GD-8
ASSEMBLY INSTRUCTIONS
Designed for Professional Frames
www.gryphondynamics.co.kr

Advertisement

loading
Need help?

Need help?

Do you have a question about the GD-8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gryphon Dynamics GD-8

  • Page 1 Rev. Nov 2013 GRYPHON DYNAMICS GD-8 ASSEMBLY INSTRUCTIONS Designed for Professional Frames www.gryphondynamics.co.kr...

  • Page 2: Specifications

    SPECIFICATIONS Dimension(mm) Model Weight(g) OT1400F 1,400 1,329 1,950 OT1200F 1,200 1,144 1,820 OT1100F 1,100 1,052 1,690 OT1200S 1,200 1,140 1,740 OT1100S 1,100 1,052 1,680 OT1000S 1,000 1,620 - Landing Gear : LG-5039TW - Weight : Exlc. Landing Gear...

  • Page 3: Motor Mount Assembly

    1. MOTOR MOUNT ASSEMBLY M3x10mm Soket Countersunk Head Screw MB-0501(Motor Connector Clamping Block) CN-0002M(Motor Mount Boom Connector) M3x8mm Soket Button Head Cap Screw EM-0601(ESC Mount) MM-0401(Motor Mount) CASE 1 CASE 2 : ESC MOUNT MS-0402(Motor Mount Surpport) M2.5x6mm Soket Head Cap Screw CASE 3 : MOTOR MOUNT REINFORCEMENT THRUST VECTORING ANGLE ADJUSTMENT Oval Hole...
  • Page 4 2. OUTER BOOM ASSEMBLY 1 NOTE : Please repeat these steps until you have 8 units. M3x8mm Soket Button Head Cap Screw : 4pcs 3. OUTER BOOM ASSEMBLY 2 M3x8mm Torx Countersunk Head Screw : 8pcs HC-0135D(Hub Connector 135D : 2pcs) NOTE : Please repeat these steps until you have 4 units.
  • Page 5 4. INNER BOOM ASSEMBLY HC-0090D(Hub Connector 90D : 2pcs) M3x8mm Torx Countersunk Head Screw : 16pcs 5. INNER & OUTER BOOM ASSEMBLY NOTE : Please repeat these steps until you have 4 units. M3x8mm Torx Countersunk Head Screw : 4pcs...
  • Page 6 6. FOLDING BOOM GUIDE RAIL ASSEMBLY M3x6mm Soket Button Head Cap Screw : 2pcs GR-0101(Folding Boom Guide Rail & Collar) M3x6mm Soket Button Head Cap Screw : 2pcs FOLDING BOOM CONNECTOR DETAILED DRAWING M3x4mm Hexagon Soket Set Screw LN-0204(Lock Knob) ONLY CLOCKWISE DIRECTION Neodymium Magnet(Φ4x2mm) RL-0203(Rolling Locker)
  • Page 7 7. CENTER PLATE / TOP CP-2416OT CP-0101GP CM-0846 (8x46mm Cross Member) : 4pcs CP-0100BT CL-0100V : 4pcs Top View M3x6mm Soket Button Head Cap Screw : 24pcs CM-0820 (8x20mm Cross Member) : 8pcs Bottom View M3x6mm Soket Button Head Cap Screw : 12pcs...
  • Page 8 8. CENTER PLATE / BOTTOM M3x6mm Soket Button Head Cap Screw : 8pcs CL-0100V(Boom Clamp : 4pcs) CM-0846(8x46mm Cross Member : 4pcs) EC-1012(PVC End Cap : 4pcs) CB-4012GR(Gear Rail : 2pcs) Direction Mark Top View M3x6mm Soket Button Head Cap Screw : 12pcs CL-108(Gear Rail Boom Clamp) : 4pcs M3x12mm Soket Button Head Cap Screw : 4pcs Direction Mark...
  • Page 9 9. CENTER PLATE & INNER BOOM ASSEMBLY(T-TYPE) M3x6mm Soket Button Head Cap Screw : 18pcs...
  • Page 10 10. CENTER PLATE & INNER BOOM ASSEMBLY(I-TYPE) M3x6mm Soket Button Head Cap Screw : 12pcs...

  • Page 11: Appendix 1 : Landing Gear(T-Type) Assembly

    APPENDIX 1 : LANDING GEAR(T-TYPE) ASSEMBLY M3x6mm Soket Button Head Cap Screw(4pcs) M3x6mm Soket Button Head Cap Screw(2pcs) M3x8mm Soket Button Head Cap Screw(2pcs) CL-0100H(Boom Clamp : 2pcs) M3x6mm Soket Button Head Cap Screw(2pcs) CP-0102LG(Landing Gear Guide Plate & Spacer) M3x8mm Soket Button Head Cap Screw(2pcs) A-Type : M3x12mm Soket Button Head Cap Screw B-Type : M3x20mm Soket Button Head Cap Screw + M3 Nylon Lock Nut...

  • Page 12: Appendix 2 : Landing Gear(I-Type ) Assembly

    APPENDIX 2 : LANDING GEAR(I-TYPE ) ASSEMBLY M3x6mm Soket Button Head Cap Screw CL-0100H(Boom Clamp) M3x6mm Soket Button Head Cap Screw CP-0102LG(Landing Gear Guide Plate & Spacer) A-Type : M3x12mm Soket Button Head Cap Screw B-Type : M3x20mm Soket Button Head Cap Screw + M3 Nylon Lock Nut M3x8mm Soket Button Head Cap Screw CB-3920(Landing Gear Boom) The length of cabon boom...
