roke modelle AS W 19 Building Instructions

Building instructions for the ROKE AS W 19
Thanks for the confidence into our products, which you proved with your purchase decision.
The fact, that your decision was correct will be noticeable to you surely with the view of the
supplied parts.
All supplied parts are 100 % "made in GERMANY by ROKE", and the worth of that, you´ll see
when you´re assembling and flying this model. Should emerge questions during the building
phase or later, don´t hesitate to contact us by phone within the office hours. Say us only the
model-name, number of fuselage and wing, and we can discuss and eliminate immediately
the ambiguity.
This free telephone service applies, as long as you possess the model. That's ROKE!
Safety references
Read and obey the building instructions.
•
Do not make changes of the intended building method and at the intended materials. If
you use other accessories or materials , make sure over their quality and efficiency.
•
Consider above all also the data to the position of the center of gravity, the rudder
deflections and the references to trimming and flying.
•
Please do not improvise anything at the model, if on the flight area somewhat does not
function correctly..
•
An out of control gotten flight model can be a substantial danger for you and others. A
liability insurance can release you from large problems, if despite all caution damage
happens.
•
Act responsibly and safetyconsciously; this begins with the building and ends after flying the
model. You not only recompence yourself thereby, but help also to receive and spread the
beautiful and instructive model flight haven.
Warning!
Remote controlled flight models are not a toy in the usual sense. Their building and enterprise
requires technical understanding, care relating to crafts and safetyconscious behavior. Errors
or carelessness when building or flying can cause damages to property or personal injuries.
Because manufacturers or salesmen do not have influence on normal building and enterprise
of the flight model, expressly these dangers are called and any responsibility is excluded!
Some words to flight physics and to the model.
Although our models should be flown actually elegantly and calmly (evenly model-faithfully),
they exhibit nevertheless substantial security reserves, which concerns the maximum stress.
For the AS W 19 the permissible load factor is 10 G. . That means, that during flight maneuvers
the complete fuselage with tail-units may charge up to its 10-times of its weight the wings
without damage.
