Qazqa Scout WL Dark Grey Instruction Manual

Scout WL Dark Grey
92301
0
6X27
4
8
Unchangeable LED
Important:
Max.6x0.5W LED
3000K±300K
period of up to 3 days (for 1800mAh Li Battery) before switching on the lights, in order that
10000H
the lights work on a full charge
3.7V
1800mAh
LI-ION
Rechargeable
HOW TO DETERMINE WHERE TO MOUNT YOUR SOLAR PIR SENSOR LIGHT
battery
█
The most important thing to remember for the operation of your SOLAR PIR SENSOR LIGHT is that
III it works from the power contained in DIRECT SUNLIGHT. The more direct sunlight the solar cell
receives in a day, the longer the light will operate.
■ Main Unit:
IP44
The main unit contains 6*0.5W LED, motion sensor and battery (3.7V 1800mAh LI-ION
Rechargeable battery). When deciding where to mount this unit, keep in mind that the motion
sensor that actives the light has a " eld of vision" of min. 7 meters (in front of the light) and about
90º (horizontal) at 25℃ environmental temperature.
■ Solar Cell:
The solar cell is the power source for the SOLAR PIR SENSOR LIGHT. It converts the sun's energy
into electricity that charges the battery stored in main unit. This requires DIRECT SUNLIGHT
falling onto the face of solar cell for as long as possible over the course of day.
CLEANING
█
It is important that the solar panel is kept free of dirt and debris. A dirty solar panel will not allow
G U A R A N T E E
the battery to fully charge and this will shorten the life of battery and cause the light to malfunction
2 Y E A R S
INSTRUCTION MANUAL
1
6x 6x
2
ST4x30mm
1
5
ST4x30mm
4 M
Please ensure that you charge the solar lights in maximum sunlight for a
2
6
AUTO
10.1cm
7 M
3
φ6mm
30mm
7
12.1cm
