Summary of Contents for Uni-ram URS900SSW
- Page 1 USER MANUAL URS900SSW FOR RECYCLING WATER ONLY DO NOT USE TO RECYLE SOLVENT UNI-RAM CORPORATION • ONTARIO • CANADA Revision 2011-07...
-
Page 2: Table Of Contents
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 CONTENTS INTRODUCTION ........................... 3 SAFETY APPROVALS, CAUTIONS AND WARNINGS ................ 3 FEATURES AND SPECIFICATIONS ....................4 SAFETY FEATURES ..........................4 PREPARATION AND SETUP, INCLUDED PARTS ................5 LOCATION AND CONNECTION ......................5-6 DIRTY WATER MIXTURE ........................ -
Page 3: Introduction
Revised 2011-07 INTRODUCTION Uni-ram holds many patents on designs used in its innovative products. Every machine is tested for com- pliance with Quality Assurance standards. Follow the instructions on preparation, use and operation to operate this machine safely and effectively. Ensure that this manual is readily available to the operator at all times. -
Page 4: Features And Specifications
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 FEATURES AND SPECIFICATIONS All Uni-ram Recyclers feature rapid-start direct electric heating (so there is no diathermic oil to change) as well as high-effi ciency condensers, air cooled with a motor driven fan. MODEL... -
Page 5: Preparation And Setup, Included Parts
STRONG, HEAT RESISTANT AND CHEMICAL Liquid Outlet Tube RESISTANT. Tank Filters, 2 Spares USE OF A NON-UNI-RAM LINER BAG MAY VOID THE WARRANTY. LOCATION AND CONNECTION: This unit is certifi ed for use in non-hazardous locations and hazardous locations Class 1, Division 1 Group D and Class 1, Division 2, Group D. -
Page 6: Dirty Water Mixture
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 can freely move in and out of the cabinet. The unit must be in a location where people or equipment cannot disturb the power cord or connection. The cord must be connected directly to the main power supply;... - Page 7 MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 2) Fill the Distillation Tank a) First remove the Tank Filter Pad and the Tank Screen. b) Pour the dirty water mixture into the Distillation Tank up to 4 INCHES BELOW THE RETAINER RING.
- Page 8 MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 6) Recycling On fi rst power up and when the unit is ready to begin a new cycle, the Display Panel shows “READY S.P. = XXX°C” (S.P. = SET POINT). When Setup is complete and START has been pressed, the “HEAT”...
-
Page 9: Manual - Solvent Recycler - Urs900Ssw Revised
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 Caution: Ensure that the bag material does not block the Vapor Outlet. 13) Inspect Lid Gasket, Remove and Replace if necessary as required Inspect the Lid Gasket for shrinking, hardness and cuts. The Lid Gasket is a wear item as it is exposed to high temperature vapor during distillation. -
Page 10: Theory Of Operation
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 THEORY OF OPERATION - DISTILLATION PROCESS The liquid waste mixture consists of water and solid materials picked up during spray gun cleaning. Re- cycling separates the water from the waste materials. During the recycling process, the distillation tank fi... -
Page 11: Troubleshooting Guide
Carry out each action step until a solution is found. If the recommended actions do not solve the problem call Uni-ram Service in North America or contact a qualifi ed Service Technician. Caution: Disconnect the power supply before conducting maintenance or service. -
Page 12: Test Mode
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 PROBLEM CAUSE ACTION STEPS Water vapor leaks from the Lid 1) The Lid Gasket has 1) Replace the Lid Gasket (See Operating Gasket excessive wear as Procedure 11). indicated by cracks, shrinkage, hardness 2) The liquid fl... -
Page 13: Error Messages
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 ERROR MESSAGES If an abnormal condition is detected by the unit’s Self-diagnostic System, the Display Panel shows one of the following error messages: MESSAGE POSSIBLE CAUSE ACTION BOILING TIME OUT • Boiling did not occur within the •... -
Page 14: Service Procedures Including 6-Month Maintenance
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 SERVICE PROCEDURES 1) CLEAN CONDENSER Remove the screen at the back of the unit that covers the condenser and vacuum the condenser using a brush attachment. Re-install the screen. 2) CLEAR BLOCKED LIQUID FLOW PATH CAUTION: WEAR SAFETY GOGGLES. - Page 15 MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 4) INCREASE LID TENSION (BY ADJUSTING THE SPRING BOLT) CAUTION: SHOULD BE DONE ONLY AS A LAST RESORT - FIRST CHECK FOR A WORN LID GASKET, A BLOCK- AGE IN THE LIQUID FLOW PATH , LOOSE HINGE BOLTS OR A SET POINT THAT IS TOO HIGH FOR THE MIXTURE BEING RECYCLED.
-
Page 16: Replacement Parts
MANUAL - SOLVENT RECYCLER - URS900SSW Revised 2011-07 REPLACEMENT PARTS DESCRIPTION PART NO. SAFETY COVER 770-3311 KEYPAD 900-3461 DIAPHRAGM PUMP UDP4TA DOOR HANDLE & 2 SCREWS 120-318F & 99-404S LID GASKET, NEOPRENE 770-2150N LIQUID OUTLET TUBE 770-8131 LIQUID RECEIVING PAIL... -
Page 17: Warranty
“Conditions of Warranty” as consumables are not covered. Uni-ram reserves the right to direct the customer to ship the unit collect to the Uni-ram factory or to an ap- proved Service Center for repair using the Uni-ram Return Goods Procedure or to repair the unit on-site.
