Summary of Contents for Evers WATER WONDER Mini
- Page 1 Instruction manual ® EVERS WATER WONDER mini...
- Page 2 Instruction manual for ® EVERS WATER WONDER mini type micro/ultra Introduction Thank you very much that you chose an EVERS water filtration system. You’ll find information about the performance, operation conditions, storage and operation of the system in the product description. Application...
- Page 3 4. If the filter system is to be integrated into a drinking water system already in operation please make sure that the tap water is disinfected after installation. Information of how to carry out disinfection can be found on page 10 and 11 of our flyer. 5.
- Page 4 Tools and materials for the installation that are not included in the delivery scope cross slot screw driver drilling machine adjustable screw driver suitable fixing material installation material (water pipes) connecting piece for the water pipe flexible tube pipe cutter Fixing of the filter unit 1.
- Page 5 Installation of the gate valve 1. Install the 3 recommended gate valves as shown in drawing 1 2. Gate valve 1 and 2 are used to shut off in case of demounting of the filter unit. Valve 1 and 2 are closed, valve 3 is open. Thus unfiltered water can go directly to the main water tap.
- Page 6 Changing the filter elements (drawing 4 and 5) The filter system consists of 2 units: Prefilter (drawing 4) and main filter (drawing 5) The durability of the filter elements most of all depends on the water quality. When the water flow of the tap decreases it might be an indication of a bad water quantity and not of a defective filter.
- Page 7 Applied technologies Membrane technology for ultimate dirt Hollow fibre membranes consist of billions microscopically small pores small enough to retain micro organisms but big enough to let through water molecules and vital minerals. Today, it is no problem to install this hollow fibre membrane technology into filter cartridges that can immediately be used.
- Page 8 drawing 1: - 7 -...
- Page 9 drawing 2 - 8 -...
- Page 10 drawing 3 - 9 -...
- Page 11 90° rotation prefilter filter cartridge drawing 4 drawing 5 - 10 -...
- Page 12 EVERS e.K. WATER TECHNOLOGY and FILTER MATERIALS Member of: Rheiner Str. 14 a D-48496 Hopsten, Germany Phone.: +49 5458 9307 0 Fax: +49 5458 9307 40 Email: info@evers.de...
