Summary of Contents for Ya Suh Dar Y16-AC
- Page 1 Ceiling Fan Manual...
- Page 2 Ceiling Fan Power Model Voltage R.P.M Consumption (Maximum) High 45~43 W Y16-AC 110V Y15-AC Medium 40~31 W 60Hz Y14-AC 36~24 W High 25~22 W Y16-DC 110V Y15-DC 220V Medium 15~12 W Y14-DC 50/60Hz 10~8 W High 45 W Y16-AC-2 220V...
- Page 3 Standard Equipment 1. Ceiling fan × 1 unit 2. Remote control with batteries × 1 set Installation Guide ★Please use the wire is 1.6mm-2.0mm 1. Remove the ceiling tile 2. Put the ceiling fan to the ceiling 3. Let the ceiling fan still horizontal with ceiling. 4.
- Page 4 Notice of operating 1. Please do not block the blades or the turntable when the ceiling fan is operating. 2. Please do not use any spray on the ceiling fan. 3. The limitation of environment The voltage have to within the certain range: 110V±10%/220V ±10% Temperature of environment：0 ~ 45℃...
- Page 5 discarding batteries. Dismantling and Maintenance Please turn off /disconnect the power before dismantling and do the maintenance. 2. Take apart the housing (The housing of Y14-Fan series are different, but the way of dismantling is the same ) Take out the screws at the corners of housing (4 Pcs) Take out the housing...
- Page 6 3. Dismantle the blades Loose the center clockwise and take out the blades When do the installation, the blades have to install properly on the axis.
- Page 7 Do not wash the base of ceiling fan by water. The blades and the center are washable, but they have to be dry before assembling. 4. Dismantle the turntable Loose the cover of turntable anticlockwise and take out the turntable When do the installation, the turntable have to install on the fixed mount.
- Page 8 Installed unevenly Do the installation again Strange noises There are foreign objects Check the inner of in the ceiling fan ceiling fan Ya Suh Dar Co.,Ltd Head Office No.332,Lane 549,Sec.2,Sanfang Road, Fengyuan Dist., Taichung, Taiwan 42073 04-25278062 04-25293889...
