Primetime PTC13 Instructions

Step 7
All VANTAGE POINT products are manufactured to ensure superior quality, performance and durability for a lifetime of use. Warranty covers the product to be free
from defects in the materials and workmanship under normal and reasonable use. Vantage Point Products will repair or replace, at our option, any product which
proves to be defective upon our inspection. This warranty will not apply to products which have been lost or damaged by misuse, abuse or accident, altered or
repaired in any way by any person or firm other than us, used in violation of instructions or an incorrect assembly nor used in a manner other than specified by
us. The warranty is nontransferable to a new owner and may require proof of purchase. All claims must be directly handled with Vantage Point Products Corp.
Before placing the television on the ceiling mount, slide the safety strap (K)
through both front slots on the platform (E), as shown. Have the safety strap
(K) hang down from the platform ready for the television placement. Next, with
adequate assistance place the television on the ceiling mount and secure the
safety strap (K) immediately, as shown.
Δ Deter tampering with the safety strap (K) by locating the strap buckle on the
top of the television.
Preview all 7 steps before beginning. Should any portion of these instructions be unclear, contact a qualified contractor, handyman or call us
direct at 800-582-9595 for assistance. Do not attempt to install this Vantage Point television ceiling mount if you have any doubts as to its proper
installation. CAUTION- This Television Ceiling Mount is intended for use only with maximum weight indicated. Use with heavier than the maximum
weights indicated may result in instability causing possible injury. Use of this product for any other purpose unless specified by Vantage Point
Products is not recommended. Think safety first!
Δ INDICATES TO NOTE CAUTION, WHICH IF NEGLECTED MAY RESULT IN AN IMPROPER OR UNSTABLE ASSEMBLY.
G
H
I
6i04-07/03
Vantage Point Products Corp.
U.S.A. Tel: 562.946.1718 • Canada Tel: 905.607.9994 • Web Site: www.vanptc.com • Email: cons-serv@vanptc.com
Television
Ceiling Mount Instructions
For Models PTC13 and PTC20
FIG. ITEM
A Platform Bolt
A
B Indexing Washer
B
C Ceiling Plate
D Plastic Cover
C
E Platform
D F Bearing Ring
G Steel Frame
Installed at
F
H Flange Nut
factory
I Dome Cap
J Lag Screw
K Safety Strap
B
E
A
J
B
Installed
F
at factory
SPECIFICATIONS and
B
TV SIZE MODEL # IN BLACK
H
13" – 17" PTC13-B
I
19" – 21" PTC20-B
25" – 27" PTC26-B
* TESTED TO 4 TIMES MAX. LOAD RATING By Underwriters Laboratories Inc.®
• P.O. Box 2485, Santa Fe Springs, CA 90670
DESCRIPTION QTY
3/8"-16 x 2-1/2" custom hex head bolt 2
3/8" custom indexing flat washer 4
Steel ceiling plate 1
Plastic rounded ceiling plate cover 1
Steel platform 1
3" plastic bearing ring 2
(installed at factory)
"C" shaped tubular steel arm 1
3/8"-16 serrated flange nut 2
3" plastic Dome cap 2
#14 x 2-1/2" hex head lag screws 4
1-1/2" polypropylene strap 1
Tools
K
Required
RATINGS
MODEL # IN WHITE MAX. LOAD LISTED
PTC13-W 60 LBS. YES*
PTC20-W 60 LBS. YES*
PTC26-W 80 LBS. YES*
