User Manual of Outdoor MDU 208 Splitter Terminal
Description
The MDU 208 Splitter Terminal from Alternetivo
is not only rugged, but low cost, low profile
interconnection
between
multi-dwelling units of FTTx application.
The design of MDU 208 splitter terminal combines
the functionality of a local convergence cabinet with
MDU terminal.
Its multi-layer design allows installers to access
only
the
components
installation or subscriber turn-up. It can house the
splitter
and
allows
distribution/drop cables as needed
Features
· Indoor or outdoor rated
· available 1x4, 2X4,1x8 splitter as well as splitter
· Max. up 8 pcs of FTTH drop cable or pigtails
· Suitable for wall-mounting or pole mounting
application
· 2 pcs of inlet ports and 8 pcs of outlet ports
Application
· FTTH, FTTB, FTTC
· Telecommunication Network
· CATV
· Local Area Network200mm(W)x215mm(H)x54mm(D)
Dimensions
Model
MDU 208
central
office
and
necessary
for
initial
for
pigtail
splicing
of
PLC Splitter
1x4, 2x4, 1x8,
www. alternetivo.cz
Outdoor MDU 208 Splitter Terminal
MDU 208 splitter terminal
Dimension(mm)
(WxLxD)
200x215x54
No. of Ports
2 input ports and
8 output ports
