Custom Dynamics GEN200-KIT-1157 Installation Instructions Manual

We thank you for purchasing Custom Dynamics® LED turn
signal clusters! Our Genesis® LED's offer maintenance free
service and higher visibility. We offer one of the best warranty
programs in the industry and we back our products with excel-
lent customer support, if you have questions before or during
installation of this product please call Custom Dynamics® at
1(800)382-1388.
GEN-200-AW-1157
NOTE: This product is designed for dual intensity front
turn signal fitment only. They will not function properly
in the rear.

Instructions

1. Remove lens from turn signal housings.
2. Remove bulbs from turn signal housings.
3. Be sure contacts are clean.
4. Insert base of LED cluster into housing making sure that
the alignment notches on the sides are properly oriented and
fully seated.
5. Twist cluster to coil wire and insert cluster into housing.
6. While holding cluster in place, reinstall lens.
GEN-200-R-1157
NOTE: These products are designed for Rear turn signal
fitment only.
Instructions
1. Remove lens from turn signal housings.
2. Remove bulbs from turn signal housings.
3. Be sure contacts are clean.
4. Insert base of LED cluster into housing making sure that
the alignment notches on the sides are properly oriented and
fully seated.
5. Twist cluster to coil wire and insert cluster into housing.
6. While holding cluster in place, reinstall lens.
Have Questions? Call us at: 1 (800) 382-1388 M-TH - 8:30AM-5:30PM EST / FR - 9:30AM-5:30PM
2010-2013 Street Glide® and Road Glide® Custom, 2010-2011 Dyna® Street Bob and
Wide Glide, 2010 Softail® Convertible CVO™ (models without a center taillight)
GEN-200-A-1157E3
GEN-200-RR2-1157
PN: GEN200-KIT-1157
Fits all Harley-Davidson® Models listed below:

LED Turn Signal Tips and Troubleshooting:

1. Dielectric grease does not need to be used with this
LED product, it can prevent them from working. Re-
move any excess from your turn signal sockets before
inserting.
2. Make sure you have the orientation correct before in-
serting the base. If it seems hard to twist in the socket, it
is probably in the wrong way.
3. Harley Davidson® Bullet turn signals may require trim-
ming of black gasket to fully seat lens.
4. Install the Smart Signal Stabilizer™ before testing Turn
signals.
5. If LED turn signal does not function correctly, clean the
bottom contacts, then re-insert. Also try in the other turn
signal socket.
GEN2-SS6

Installation Instructions

This unit is alarm compatible and 4-way haz-
ard compatible. When using the 4-way hazards
with this product installed, the security key light on
the dash will come on. This is normal when in
hazard mode and will reset when turned off.
1. Make sure bike power is off.
2. Locate stock connector block for taillight/turn signals under
seat. If an aftermarket Run/Brake/Turn module is installed,
Smart Signal Stabilizer™ MUST go before Run/Brake/Turn
module.
3. Unplug main harness connector from fender harness
connector.
4. Plug Smart Signal Stabilizer™ in between these two con-
nectors.
5. Before turning power on, make sure the load switch on the
side of the stabilizer is in the "normal" position. (See next
page for Diagram).
6. Turn Ignition on, but do not start the bike. Activate the
right turn signal, allow to flash 2 times. Activate the left turn
signal, allow to flash 2 times. Activate the right turn signals
again for at least 10 flashes. Activate the left turn signal for
at least 10 flashes. Turn the ignition off and back on Check
the function of the turn signals.
11-2017
