explorer compact GL8898 User Manual

OPERATION
Switch on Camera
1. Press and hold on the power switch for about 3 seconds
to turn on the camera, the power indicator will illuminate and
the LCD will become viewable.
2. When in use, the tube should easily maneuver itself into position.
Do not apply excessive force.
3. The flexible tube can be bent into numerous shapes that may
help you explore areas you otherwise thought were impossible
to see.
4. The accessories included with EXPLORER COMPACT can be
used to retrieve small items like dropped rings or screws.
Mirror Image
In real-time monitoring mode, The mirror image can be adjusted
by pressing the button.
Normal Mirror Normal Upside Down Mirror Upside Down
LEDs Brightness Control
The 8 levels of LED brightness can be adjusted by pressing
the brightness button in real-time monitoring.
LCD Contrast Control
The 8 levels of LCD contrast can be adjusted by pressing
the contrast button in real-time monitoring.
SPECIFICATIONS
Model No. Parameter
"
Screen Size 2.31 TFT LCD
Contrast 300
Brightness 2
220CD/M (TYP)
Power Supply
AA x 4 batteries (1.5V x 4)
Work Time
6Hour (Max.)
Consumption Current 238mA
Output Signal Impedance 75ohm
Output Signal Level 0.9--1.3Vp-p
Imaging Sensor
1/9-inch CMOS
Effective Pixels
640 x 480
Video System PAL/NTSC
Horizontal Viewing Angle 48 O
Minimum Illumination 0 Lux (LED ON)
Waterproof Capacity IP67 (for lens/tube only)
Dimensions of T ube 8mm x 980mm (Including Camera)
257 x 92 x 44(mm) (Excluding Flexible T ube)
Dimensions of Handle
Operating T emperature O O O O
-10 C ~50 C /14 F~122 F
Operating Humidity 15~85%RH
Approx. Weight 407g (Including Batteries)
※ All specifications are subject to minor change without prior notice.
FCC INFORMATION
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference;
(2) This device must accept any interference received, including
interference that may cause undesired operation. Changes or
modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the
equipment.
EU Environmental Protection
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
local authority or retailer for
recycling advice.
Inspection Camera
with Color LCD Monitor
INSPECTION TOOL
Version 1.0
Please read this user manual carefully before using this product.
Failure to understand operation procedures may result in injury.
Model：GL8898
