Studio Assets MegaMast SA1250 Instructions

MegaMast Stabilizer Instructions
Contents
A
A) Ropes with Pulleys
C
B) Collar with Arms
C) Top Plate
B
Step 1
Unscrew the head and
place the top plate onto
the MegaMast. Then
Screw the head back
onto the mast.
Step 2
Attach the clips on the
ropes to each of the
three holes on the top
plate.
Notes
• The pulleys can be attached to tent stakes
in the ground for greater stability.
• Do not over-tighten the ropes. Pull each
one a little at a time until they are snug.
Step 3
Attach the collar & arms
to the 4th from the
bottom riser section on
the 27.5' MegaMast or
the 3rd from bottom
riser on the 23' version.
Step 4
Raise the mast to the
desired height. Then
attach the pulleys to the
hooks on the legs and
pull the ropes snug.
