1
Air Inlet Connection
2
Wiring Harness
3
Cooler, complete with DC fan motor
4
Air Outlet Connection
5
Pressure Switch
6
Discharge Hose
7
Water Separator
8
Moisture Separator Drain Valve
9
System Depressurization Valve
'
With alligator clips or terminal rings
12 volt, 24 volt option
Locate on the front of the cooler
N/0, set@ 12 psi, (2) spade connector
1" high pressure
No spare parts required
....
- -
•••
1
2
3
Advertisement
Summary of Contents for TDM DryAIR 400
- Page 1 ..••• Air Inlet Connection Wiring Harness With alligator clips or terminal rings Cooler, complete with DC fan motor 12 volt, 24 volt option Air Outlet Connection Locate on the front of the cooler Pressure Switch N/0, set@ 12 psi, (2) spade connector Discharge Hose 1"...
- Page 2 --'- ••a ••• OPERATIONS GUIDE-TOM DRVAIR 400 AFTERCOOLER 1. Unit is sized for 400dm @ max 200psi. Optimal performance will be achieved at operating pressures above 90psi. 2. Connect unit to portable battery using either the alligator clip or ring terminal adaptors which are supplied with the unit.
