Dogberry Collections DOGB001 Installation Instructions Manual

Wall Mounted Mantel Shelf – Suggested Installation Instructions
1. Important: wood mantels are considered a combustible material, so heat clearances must be adhered to.
Before installing, check your local building codes and the manufacturer's instructions for your specific
fireplace insert or stove.
2. Parts included

(1) mantel shelf

(1) hanger board (narrow unfinished board)

(4) short screws

(3) long screws (these screws are only for attaching to wall studs - NOT brick or drywall)
3. Minimum tools required

Pencil or pen

Tape measure

Phillips screwdriver
4. Optional tools (not required, but may be helpful)

Stud finder

Level

Drill

Phillips drill bit

1/16" drill bit
5. INSTALLATION (in order)

Determine location and measure
o First, measure the width of your mantel shelf (should be 36", 48", 60" or 72")
o Using a pencil, mark on the wall where you would like the left and right side of your
mantel shelf to be.
o Within those marks, locate 3 studs (2x4 boards) inside the wall you will be mounting to.
If you can only find 2 studs that will suffice, but 3 studs is recommended. For 36"
mantels, 2 studs is sufficient.
o After locating the studs, make a pencil mark on the center of each stud located ¾"
below the desired location of the top surface of the mantel shelf (see image below).
o Use a level or tape measure to check that wall marks are at the same height.
o Then make corresponding pencil marks on the hanger board, such that the hanger
board will be centered above your fireplace (or desired location).
¾"
hanger board
(centered above fireplace)
desired location
of top surface of
mantel shelf
make marks
corresponding to
location of studs
