Rinnai RR-55J Owner's Operation And Installation Manual

Gas rice cooker

Advertisement

Quick Links

THIS MANUAL MUST BE READ IN ITS
ENTIRETY BEFORE OPERATING GRIDDLE
Owner's Operation and Installation Manual
WARNING: Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
WARNING: If the information in these instructions is not followed
exactly, a fire or explosion may result causing property damage,
personal injury or death.
– Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
– Do not store or use gasoline or other flammable vapors or liquids in
the vicinity of this or any other appliance.
– The purchaser must post in a prominent location instructions to be
followed in the event the user smells gas. Instructions can be obtained
by contacting the local gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in
your building.
• Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
INSTALLER: MUST LEAVE MANUAL WITH UNIT AFTER INSTALLATION.
OWNER: RETAIN THIS MANUAL SAFELY, FOR FUTURE REFERENCE.
OWNER/INSTALLER
FOR YOUR SAFETY
RR-55J
GAS RICE COOKER
FOR YOUR SAFETY

Advertisement

Table of Contents
loading

Summary of Contents for Rinnai RR-55J

  • Page 1 OWNER/INSTALLER FOR YOUR SAFETY THIS MANUAL MUST BE READ IN ITS ENTIRETY BEFORE OPERATING GRIDDLE RR-55J GAS RICE COOKER Owner’s Operation and Installation Manual WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
  • Page 2: Table Of Contents

    1. Cleaning .........................8 2. Troubleshooting ......................8 3. Service ........................9 Parts List and Diagrams....................10 Limited Warranty ....................14 Model Number RR-55J Gas Rice Cooker Manufactured by Rinnai Japan Distribution by Rinnai America 1662 Lukken Industrial Drive West LaGrange, Georgia 30240 Phone 1-800-621-9419 Fax-1-706-884-6099 E-mail rinnaiservice@mindspring.com...
  • Page 3: Name Of Parts

    180 ml (5.3 oz) RICE POT HEAT SHROUD PILOT VIEW HOLE MUST ALIGN WITH CONTROL KNOBS DRIP PAN BASE SPECIFICATIONS y t i – " 2 " 1 " 5 " 5 " 5 " 0 " 6 Model RR-55J 800-621-9419...
  • Page 4: Installation Instructions

    3. Provide adequate clearance for air openings into the combustion chamber. Clearances Minimum clearances from combustible materials are as follows: 6" from side and 6" from back. Minimum clearances from NON-combustible materials are as follows 0" from side and 0" from back. www.rinnaiamerica.com Model RR-55J...
  • Page 5: Operating Instructions

    * When igniting make sure not to put your face near the viewing holes. * If it is hard to see the PILOT flame, relocate the position of the shroud so view holes are directly over controls. See pages 3 and 7. Model RR-55J 800-621-9419...
  • Page 6: How To Cook Rice

    To suit your needs and tastes, you may need to adjust the water level. B. Do not put water over the top line of Water Level Guide. Soak rice in water about 30 minutes before you start cooking. www.rinnaiamerica.com Model RR-55J...
  • Page 7: Visual Burner Check

    Make sure the view hole is directly over controls. Make a visual check of main and pilot burner flames. Flame should be light blue in color and should have no yellow tips or lifting from the burner. Do not hold face near view hole while igniting. Model RR-55J 800-621-9419...
  • Page 8: Maintenance/Service

    . t i t o l e l i t o l c i f t o l c i f n i l y l l a l l www.rinnaiamerica.com Model RR-55J...
  • Page 9: Service

    FOR MAINTENANCE REPAIR, CONTACT FACTORY, FACTORY REP, OR YOUR LOCAL SERVICE COMPANY. SERVICE RINNAI AMERICA CORPORATION 1662 LUKKEN INDUSTRIAL DRIVE WEST LAGRANGE, GEORGIA 30240 TEL: 800-621-9419 FAX: 706-884-6099 Model RR-55J...
  • Page 10: Parts List And Diagrams

    P A R T S L I S T A N D D I A G R A M S www.rinnaiamerica.com Model RR-55J...
  • Page 11 P A R T S L I S T A N D D I A G R A M S Model RR-55J 800-621-9419...
  • Page 12 P A R T S L I S T A N D D I A G R A M S www.rinnaiamerica.com Model RR-55J...
  • Page 13 Pilot Orifice (Instant) (for Nat.) dia. 0.65 6541-96 Ignition Pilot Tube BRR37-403-2 Connecting Tube Push Metal ARR37-333 Washer CP-20805 O-Ring C5G1-8 Electrode CP-50188 Plug Holder CP50709 Measuring Cup RR79-4951 Instructions TRER-55AS-IAS Rating Plate BRR37-943 Warning Label BRR37-945 Instruction Label BRR37-944 Model RR-55J 800-621-9419...
  • Page 14: Limited Warranty

    Rinnai does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, application engineering, installation, use, removal, return, or replacement of its equipment;...
  • Page 15 N O T E S Model RR-55J 800-621-9419...
  • Page 16 Rinnai’s other fine products: The Silent Servant North America’s only vent-free convection heater 99% efficient whisper quiet perfect for hard to heat areas The Energy Savers Direct Vent Heating with style and performance whisper quiet available with multi-step set back thermostats...
