Avantco Equipment 177CU30 User Manual

Avantco Equipment 177CU30 User Manual

Stainless steel coffee urn

Advertisement

Stainless Steel Coffee Urn
Models: 177CU30
Please read and keep these instructions. Indoor use only.
www.AvantcoEquipment.com
User Manual
User Manual
11/2018
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 177CU30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avantco Equipment 177CU30

  • Page 1 User Manual User Manual Stainless Steel Coffee Urn Models: 177CU30 11/2018 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
  • Page 2: Table Of Contents

    User Manual NOTE: Save these instructions for future reference. Index Important Safety Information ............. 3 Parts Diagram ..................4 Specifications ..................5 Coffee Measuring Guide ..............5 Prior to First Use ..................6 Helpful Hints ..................6 How to Use ...................6 Boil Dry Protection & Manual Reset Button ........7 Cleaning &...
  • Page 3: Important Safety Information

    User Manual IMPORTANT SAFETY INFORMATION 1. Read all instructions carefully. Remember to follow basic safety measures when using electrical equipment. 2. Only use urn with a grounded 120V AC socket. 3. Do not use the coffee urn if the cord or plug is damaged. Replace before use. a.
  • Page 4: Parts Diagram

    User Manual Parts Diagram Parts Key Part Name Replacement Part Item # Lid Handle Stainless Steel Body Cool Touch Handles Faucet Plastic Bottom On/Off Switch Stem 177CU30STEM Brew Basket 177CU30BSKT Fuse Pictured www.AvantcoEquipment.com...
  • Page 5: Specifications

    User Manual Specifications MODEL NO. POWER VOLTAGE VOLUME 177CU30 950W 120V/60Hz 30 cups Coffee Measuring Guide CUPS (5 OZ. SERVING) GROUND COFFEE (8 OZ. DRY) 12-15 3/4 Cup 20-25 1 1/2 Cups 2 Cups www.AvantcoEquipment.com...
  • Page 6: Prior To First Use

    User Manual Prior to First Use 1. Remove all packaging from inside and outside of the coffee urn. 2. Bring water to a aboil, then discard. This clears the urn of any packaging residue. Helpful Hints 1. Do not use soft water. Soft water may cause the coffee basket to flood. 2.
  • Page 7: Boil Dry Protection & Manual Reset Button

    User Manual Boil Dry Protection & Manual Reset Button Boil dry accidents are the result of boiling all the water out of an urn. These kinds of accidents shorten component and product life in all water boiling appliances. To prevent boil dry accidents, this appliance is equipped with a thermal limiter with a manual reset button (see below picture).
  • Page 8: Cleaning & Maintenance

    User Manual Cleaning and Maintenance 1. Unplug the unit and pour out any remaining water or coffee. Allow the unit to cool. 2. After the urn has cooled, add hot water, brush the interior sides, and rinse with hot water until water exiting the faucet runs clear.
  • Page 9: Electric Circuit Diagram

    User Manual Electrical Circuit Diagram Thermal Fuse This coffee urn is fitted with a thermal fuse for added safety. If this appliance’s boil dry protection measures fail, its thermal fuse will activate and shut off the appliance. The thermal fuse is a one-time-use component. Once it activates, the fuse automatically breaks and cannot be used again.
  • Page 10: Replacing The Fuse

    User Manual Replacing the Fuse Inner Parts Inspection USE THE BELOW REFERENCE FOR REPLACING YOUR FUSE Match the color references below to your unit. See next page for instructions. www.AvantcoEquipment.com...
  • Page 11: Replacing The Fuse

    User Manual Replacing the Fuse (continued) 1. Twist the fixed screw. 2. Pull out the power connection. 3. Take down the fuse fixed clip. 4. Replace the power supply leads combination. 5. Fixed new fuse. (supply leads combination) 6. Inner parts inspection. www.AvantcoEquipment.com...
  • Page 12: Limited Warranty

    User Manual Limited Warranty All equipment sold under the Avantco trademark and used for commercial purpose is warranted against defects in materials and workmanship. The warranty runs for six months from the time of purchase and is for the benefit of the original purchaser only.
