NON-INTERLOCKED HOUSING WARNING
This unit contains high power laser devices internally. Do not open the
laser housing, due to potential exposure to unsafe levels of laser radiation.
The laser power levels accessible if the unit is opened can cause instant
blindness, skin burns and fires.
LASER EMISSION DATA
Laser Classification
Green Laser Medium
Red Laser Medium
Beam Diameter
Pulse Data
Divergence (each beam)
Divergence (total light)
Laser Power
As measured under IEC measurement conditions for classification.
Version: 1.0
This manual contains important laser operation information. Read and
understand all instructions prior to powering on laser unit the first time, to
avoid laser eye injury and to avoid breaking the law. Keep this manual in a
safe place for future reference.
RG
Class 3B
DPSS Nd:YVO4, 532nm
LD GaAlAs 650nm, typical
<5mm at aperture
All pulses < 4Hz (>0.25sec)
<2 mrad
<160 degrees
Red>100mW, Green>40mW
Advertisement
Table of Contents
Summary of Contents for CR Laser FIT-D RG
-
Page 1: Laser Emission Data
NON-INTERLOCKED HOUSING WARNING This unit contains high power laser devices internally. Do not open the laser housing, due to potential exposure to unsafe levels of laser radiation. The laser power levels accessible if the unit is opened can cause instant blindness, skin burns and fires. -
Page 2: Product Overview
USER MANUAL PRODUCT OVERVIEW This device has left out premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is necessary for the user to follow the safety instructions and warning notes written in this manual. -
Page 3: Control & Function
USER MANUAL NAME DESCRIPTION Power LED Indicates the fixture is switched on Music LED Synchronize to detected music signal The laser effect output aperture. NEVER LOOK Laser Aperture INSIDE THE FIXTURE THROUGH THIS APERTURE WHILE FIXTURE IS OPERATING. Power Switch Switch ON and OFF the fixture Fuse Holder The replaced fuse is hold here... - Page 4 USER MANUAL Operation AUTO SHOW Stand Alone Mode Press FUNC to enter MODE OPTION. Till to LED panel shows AUt. Press ENTER to confirm the setting. The laser is working in standalone mode – AUTO SHOW. Each time when you turn on your laser, you will have this confirmed laser show.
-
Page 5: Dmx Mode
USER MANUAL SOUND ACTIVATED MODE sensitivity setting Press FUNC till to see S 6 Press UP/DOWN to set microphone sensitivity. S 0 is no sound activated, from S 1 to S 9, the sensitivity level is going more sensitive. Press ENTER to confirm and save the setting. DMX MODE Press FUNC to enter MODE OPTION Till to LED panel shows 001. -
Page 6: Dmx Protocol
USER MANUAL DMX PROTOCOL CHANNEL VALUE FUNCTION 000-063 Laser Block Out AUTO SHOW 064-127 CH 1 MODE 128-191 SOUND ACTIVATED SHOW (MUSIC) 192-255 DMX MODE (Other channels activated) CH 2 000-255 32 Patterns as shown in PATTERN LIST 100%-5% Size 0-127 128-169 Zooming In... -
Page 7: Pattern List In Channel
USER MANUAL 000-031 Original Color 032-063 CH 9 064-095 Green COLOR 096-127 Red & Green 128-255 Color Rolling PATTERN LIST IN CHANNEL 2 PATTERNS PATTERNS PATTERNS PATTERNS 000-007 064-071 128-135 190-197 008-015 072-079 136-143 198-205 016-023 080-087 144-151 206-213 024-031 088-095 152-159 214-221... -
Page 8: Specifications
USER MANUAL 056-063 120-127 182-189 246-255 SPECIFICATIONS Mains Input: AC100-240V, 50/60Hz Fuse: 250V 1 A Slow Blow (20mm Glass) Total Power: Music Control: Internal microphone Laser Power: 100mW-R+40mW-G CW Laser Classification: Class 3B Laser Safety Standard: EN60825-1 2007 Condition Temperature: 10~40℃...
