Summary of Contents for Rollts DOMINO D1R1
- Page 1 English Manual Overview Front Antenna Bottom 12V DC Adapter port Power switch Menu button Up / Down button Earset port Donor radio (Line In / Line Out / E&M ports)
-
Page 2: Lcd Display
LCD display The LCD display of the transceiver will be shown as 1. Channel Every kind of communication is viable between devices with a ‘ID’ and ‘CHANNEL’ that match each other. Change the ‘CHANNEL’ to ensure that you talk with only your intended people. - Page 3 Usage Market, Hotel, Sports, Leisure (Hiking, Climbing), Guide, Conference, Etc. Type High usability for any model (portable / fixed). All possible for both portable and fixed use regardless of outdoor and indoor. Communication Secures own local communication network by building a small-scale communication network.
- Page 4 DOMINO D1R1 where the indoor / outdoor communication is not good. You should install DOMINO D1R1 in a place where communication is not good and match the settings of the terminal to communicate with the transceiver. Multiple transceivers are available, and transceivers have a unique ID (ID: 1-4).
- Page 5 crossed with another group. The ‘ID’ function has a unique ID (ID: 1-4). The ‘CHANNEL’ function has 50 channels that range from 01 to 50. Move to ‘ID’ or ‘CHANNEL’ by using the ‘-’ or ‘+’ buttons after pushing the menu in the main screen.
- Page 6 Features Manual Features 900 MHz ISM license-free band Frequency hopping spread spectrum (FHSS) Resistant to narrowband interference and difficult to intercept. Bandwidth used more efficiently. Encryption (AES-256) Making eavesdropping impossible, even when set to the same channel and group using encryption technology.
- Page 7 : 3.5 mm 4 pole connector, outbound audio 1 Vp-p E&M Port : RJ 45 connector, radio audio-in and audio-out 1 Vp-p Receiver Specifications Frequency Stability : +/- 2 ppm Spurious Emissions Radiated : < 43.5 dBuV/m Blocking Immunity +/- 1 MHz : 79 dB Audio Output : E&M port audio-out 1 Vp-p...
- Page 8 FCC information to user Federal Communications Commission statement NOTE : Change or modification not expressly approved by the party responsible for Compliance could void the user’s authority to operate the equipment. NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
