Summary of Contents for B+B Sensors LogBox AA IP65
- Page 1 INSTRUCTION MANUAL Data Logger LogBox AA IP65/67 Description 01 / 25 B+B Thermo-Technik GmbH | Heinrich-Hertz-Straße 4 | D-78166 Donaueschingen Technical changes reserved Fon +49 771 83160 | Fax +49 771 831650 | info@bb-sensors.com | bb-sensors.com B+B 0141 0315-21 June 2011...
-
Page 2: Foreword
INSTRUCTION MANUAL Foreword Dear customer, We thank you for having purchased the LogBox IP65/67 and we are very glad that you decided to buy a product of B+B Thermo-Technik GmbH. We hope this product will fully satisfy you and will assist you effectively in your work. This Device has been developed to be technically highly up-to-date and has been designed in accordance with the regnant European and German national directives and rules. -
Page 3: Table Of Contents
INSTRUCTION MANUAL Content Foreword General Information Symbols Employed Warning Signs Safety Instructions Intendend Use Disposal 1. Product Description 2. Scope of Delivery 3. Optional or accessory 4. Identification 5. Properties 6. Memory Capacity 7. Input Signals 8. Operation 8.1. Drivers and software installation 8.2. -
Page 4: Symbols Employed
INSTRUCTION MANUAL 13. Most frequent problems 14. Maintenance Dimensions Technical Data Questions Symbols Employed Notice Sign Meaning It is necessary to read the following advices before using the product. Advice The used symbols in the manual acts first of all as eye catcher for secu- rity risks. -
Page 5: Safety Instructions
INSTRUCTION MANUAL Safety Instructions For damages caused by failure to observe these safety and operating instructions, takes over the B+B Thermo-Technik GmbH is not liable. This device has been designed and tested in accordance to the safety regulations for electronic devices. However, its trouble-free operation and reliability cannot be guaranteed unless the standard safety measures and special safety advises given in this manual will be adhered to when using it. -
Page 6: Intendend Use
INSTRUCTION MANUAL Intendend Use The use of the unit in fields other than those indicated under “SAFETY INSTRUCTIONS” is not allowed for safety reasons. This instruction manual does not at all substitute any additional instruction manual of connected accessoriy! Disposal This unit has been marked in accordance with the European Device 2002/96/EC on waste electrical and electronic equipment (WEEE). -
Page 7: Product Description
2. Scope of Delivery Description Article Name Article Number 1 x Data Logger LogBox AA IP65, 0568 0033 Datenlogger AA IP 65 1x CD-ROM with Logchart-II Software and a USB Treiber, 2x wires for Sensor Wiring, 1x Quick Logger Operating Instruc-... -
Page 8: Identification
INSTRUCTION MANUAL 4. Identification The identification label is on the logger body. Check if the features described are in accordance with your order. The following elements are shown in the logger front: 5. Properties Parameter Start-/stop button (S) This button can be configured to start or stop the temperature measurement process. IR communication window PC-Logger communication area. -
Page 9: Operation
INSTRUCTION MANUAL 8. Operation The logger operation mode is user-defined in the Log- Chart-II software. To access or change this configuration, the Communication interface is required. The user must install the LogChart-II software in a computer and run the logger configuration according to instructions defined in the LogChart-II installation section of this manual. - Page 10 INSTRUCTION MANUAL 6. If a prompt warns you that it does not support Windows XP or that signature verification failed, click “Continue anyway”. ® 7. The interface driver files will be copied to the computer and after a few seconds a screen is displayed informing you that the software installation has been concluded.
-
Page 11: Configuration The Logger
INSTRUCTION MANUAL 8.3. Configuration the logger Make sure the communication interface is connected to the PC-port which is selected. The interface must be constantly directed towards the communication window on front part of the logger at a maximum distance of 0,5 m. After the serial port is selected, click the “GO”... -
Page 12: General Information
INSTRUCTION MANUAL 8.4. General Information General information on the top of the screen informs about the model, serial number, logger current date/time, PC date/time, firmware version (logger model version), memory capacity and the used memory. This information is displayed in the upper part of the LogChart-II configuration screen. -
Page 13: Start Logging Field
INSTRUCTION MANUAL 8.7. Stop Loggings Function Parameter At Full Memory Loggings can be stored up to the full memory capacity is reached Wrap around Logging never stops. The LogBox will keep on recording the readings and when the memory is full it will overwrite the oldest record in a circular or wrap around manner After a defined number of readings The logger will stop logging after the number of readings defined here is reached. -
Page 14: Electrical Connections
INSTRUCTION MANUAL The parameters are: Parameter Function Defines a name (up to 8 characters) for identifying the variable to be measured in the channel Inputs The signal applied to the logger input is defined here. The list shows all the input options available. The selected option must be in accordance with the internal configuration of the jumpers J1 and J2. -
Page 15: Ip65 Model
INSTRUCTION MANUAL 9. IP65 Model Open the logger’s cover to get access to the block terminals and the configuration jumpers. Connection-cables must pass through the compress fitting located at the bottom of the case. The following figure shows the internal terminals distribution. -
Page 16: Input Connections
INSTRUCTION MANUAL 9.2. Input Connections Both models have the same input connections schema: In the IP67 version, an M8 connector is provided for signal input. Two connectors provide external access to the input channels as shown in the figure. The cables are supplied with the logger. Note: The case cover should not be opened unless it is really necessary. -
Page 17: Installation Recommendations
INSTRUCTION MANUAL 9.5. Installation Recommendations Signal wires should be installed in grounded conduits and away from power or contactor wires. Instruments must be powered only by an exclusive power supply. System failure should always be taken into account when designing a control panel to avoid irreversible damage to equipment or people. -
Page 18: Acquisitions Table Window
INSTRUCTION MANUAL 9.8. Acquisitions Table Window Data acquired by one or both input channels (user-defined) are displayed in engineering units in a table format. The table displays register number, date/time and the record values. 9.9. General information table Displays information about the logger: •... -
Page 19: Visualizing The Data
INSTRUCTION MANUAL 10. Visualizing the data Three windows support data visualization: Graph, Acquisitions Table and General Information windows. Data can be originated from direct reading from the logger or from a file previously recorded in a computer. Once the windows are open, data can be saved in a file (.lch), printed on a graph or exported to a text file (.txt or .dat). -
Page 20: Configuring The Logger - Settings
INSTRUCTION MANUAL The screen exhibits instant values of variables measured, configuration information and current logger status. The Buttons are assigned the following functions: Parameter Function Search It allows you to search for another logger or reconnect communication lost for any reason. When the handheld device finds a logger, it exhibits a new Monitoring screen with the logger information. - Page 21 INSTRUCTION MANUAL Function Parameter Title Name of the process Input 1 und 2 Informs about the inputs used by channel 1 and 2 respectively Start Defines the strategy for the logging start. Options are: Immediately The logger starts logging as soon as configuration is sent to the logger By „data/time“...
-
Page 22: Downloading Data From The Logger
INSTRUCTION MANUAL 10.3. Downloading Data from the Logger In the Monitoring screen, the Download button performs the transfer of the data from the Log-Box to the PDA. Download can be partial and it does not interfere in the ongoing acquisition process. The data base of loggings is displayed in the Recording Data screen, identified with the name assigned to the process (Title) and the date it was downloaded. -
Page 23: Observations
INSTRUCTION MANUAL 11. Observations The logger is an electronic device and some basic care is required: • When opening the device for battery replacement or connecting sensors avoid touching the circuit for not causing damages resulting from static electricity • When the device is opened, avoid liquid and/or dust contact •... - Page 24 INSTRUCTION MANUAL 15. Technical Data Features Values Inputs Thermocouples J, K, T, E, N, R, S, B, Pt100, 4 - 20 mA, 0 - 50 mV, 0 - 10 V 4 to 20 mA: 100 Ohm Measurement ranges -50...+760°C (-58...1400°F) -50...+760°C (-58...1400°F) -100...+400°C (-148...752°F) -40...+720°C (-40...1328°F)
- Page 25 INSTRUCTION MANUAL Artikelnummer Beschreibung 0568 0033 Data Logger LogBox AA IP 65, Operating temperature -40 to 70°C 0568 0034 Data Logger LogBox AA IP 67, Operating temperature -40 to 70°C 0568 0036 IrLink 3 Infrared communication interface with USB-Connector and LogChart 2 software To use with TagTemp, LogBox RHT und LogBox AA Data loggers 16.
