Garelick 89421 Assembly

ASSEMBLY INFORMATION:


Check parts against parts list.

Read instructions completely before starting assembly.

SNOW RAKE ASSEMBLY INSTRUCTIONS:

STEP 1: Insert Snow Rake angled tube (A) between top edge and tab on blade (B). Align holes, secure with bolt (C)
lock nut (D).
STEP 2: Align slot of roller (K) at blade (B) edge and push roller onto blade until roller rotates. Repeat other side.
STEP 3: Attach FLAT end of brace (E) to blade (B) by aligning holes and securing with bolt (F) and lock nut (D).
Repeat for other side.
STEP 4: Attach CURVED end of braces (E) to angled tube (A) by aligning holes and secure in place with bolt (C) and
lock nut (D).
STEP 5: Squeeze legs of snap button (J) together and insert into the swaged end of the extension tube (H). Repeat
operation for other extension tubes.
STEP 6: Slip poly grip (G) on the end of one extension tube (H). NOTE: Grip will go on easier by heating in warm
water.
STEP 7: To assemble rake for use, depress snap button (J) on pole, insert extension tube into angled tube end so
snap button pops through hole. Repeat with extension tubes (H) until complete.
Write for
A complete
EEz-In Catalog
Instructions for: 89421
SNOW RAKE ASSEMBLY

SNOW RAKE AND POLE PARTS LIST

Ref.
Part No.
Letter
A 61.002
B 61.008
C 03.080
D 03.862
E 61.004
F 03.861
G 06.605
H 61.003
J 03.232
K 06.291
Garelick Mfg. Co.
ND
644 2 Street, P.O. Box 8
St. Paul Park, Minnesota 55071
Description
Angled Tube (Snow Rake)
Blade
1/4-20 x 1-1/2" Bolt
1/4-20 Locknut
Brace
1/4-20 x 1/2" Bolt
1" Poly Grip
Extension Tube
Snap Button
Rollers
Phone: 651-459-9795
E-mail: mail@garelick.com
Website: www.garelick.com
12.646
Qty.
1
1
2
4
2
2
1
4
4
2
Rev A 09/12
