- Page 1 INSTALLATION INSTRUCTIONS 3” BULL BAR 2018 JEEP WRANGLER JL 4DR & 2DR...
- Page 2 3” BULL BAR 2018 JEEP WRANGLER JL 4DR & 2DR PARTS LIST: 3" Bull Bar 10mm Lock Washers Driver/Left Mounting Bracket 10mm Plastic Retainers Passenger/Right Mounting Bracket 10mm Hex Nuts 10mm Bolt/10mm Nut plates 8-1.25mm x 35mm Hex bolts 10-1.5mm x 35mm Hex Bolts 8mm x 24mm x 2mm Flat Washers 10mm x 30mm OD x 2.5mm Flat Washers 8mm Lock Washers...
- Page 3 3” BULL BAR 2018 JEEP WRANGLER JL 4DR & 2DR Models with steel skid plate: a. Select the passenger/right side Mounting Bracket. Attach the Bracket to the lower threaded hole in the outside of the frame with (1) 10mm x 35mm Hex bolt, (1) 10mm Lock Washer and (1) 10mm Flat Washer, (Figure 4).
- Page 4 3” BULL BAR 2018 JEEP WRANGLER JL 4DR & 2DR Passenger/Right Side Installation Pictured Front (Fig 1) Remove splash guard and bracket (arrow) Front Front (Fig 2) Insert 10mm Bolt/Nut Plate into bottom of frame and out hex hole in side of frame (arrows) 10mm x 35mm Hex Bolt 10mm Lock Washer 10mm Flat Washer...
- Page 5 3” BULL BAR 2018 JEEP WRANGLER JL 4DR & 2DR Cut two openings to clear the Mounting Brackets and Bull Bar Area to cut from splash guard Front illustrated for example only. Fig 5 (2) 8mm x 35mm Hex Bolts (2) 8mm Lock Washers (Fig 6) Attach end of Bull Bar to (2) 8mm Flat Washers...
