SLI-5460 / SLI-5460-I
Quick Start Guide
ADSL IAD – Satellite optimiced
All electrical and electronic products should be disposed of separately from the municipal waste stream via
designated collection facilities appointed by the government or the local authorities.
The crossed-out wheeled-bin-symbol indicates that the device is covered by the European Directive
2002/96/EC.
The correct disposal and separate collection of your old appliance will help to prevent potential negative
consequences for the environment and the human health. It is a precondition for reuse and recycling of used
electrical and electronic equipment.
For more detailed information about disposal of your old appliances contact your city office, the waste
disposal service or the shop where you have purchased the product.
Release V1.04 | 2010-03
Internetagentur Schott GmbH
Cent-Hoheneichstr. 11
D-96191 Trunstadt
© Internetagentur Schott GmbH, 2010. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLI-5460 and is the answer not in the manual?

Questions and answers

Summary of Contents for SCHOTT SLI-5460

  • Page 1 For more detailed information about disposal of your old appliances contact your city office, the waste disposal service or the shop where you have purchased the product. Release V1.04 | 2010-03 Internetagentur Schott GmbH Cent-Hoheneichstr. 11 D-96191 Trunstadt © Internetagentur Schott GmbH, 2010. All rights reserved.

  • Page 2: Table Of Contents

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● Safety Instructions • Place the device near an easily accessible mains wall outlet. • Use only the power supply delivered with the IAD and do not use this power supply for any other device.

  • Page 3: Scope Of Delivery

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 1. Scope of Delivery Please check whether all the following parts are included in the gift box: 1. satspeed IAD SLI-5460 (-I) 2. Power Supply 3. detachable antenna (WLAN) 4. ADSL Cable (grey) 5.

  • Page 4: Connecting The Iad

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2. Connecting the IAD The coloured sockets and the coloured cables allow an easy cabling. Use the cables delivered with the device. Be careful, because incorrect cabling or switched off devices will not work.

  • Page 5: Windows 2000

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.2.1. Windows 2000 Click on Start Settings Control Panel. Double-click on the Network and Dial- up Connections icon. The Network window appears. Double-click on the Local Area Connection icon for the applicable Ethernet adapter (usually it is the first Local Area Connection listed).

  • Page 6: Windows Xp

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.2.2. Windows XP The following instructions assume you are running Windows XP’s default interface. If you are using the Classical interface (where the icons and menus look like previous Windows versions), please follow the instructions for Windows 2000.
  • Page 7 Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● Select Obtain an IP address automatically. Click on OK on the subsequent windows to complete the configuration. Restart your computer. Internetagentur Schott GmbH Cent-Hoheneichstr. 11 D-96191 Viereth-Trunstadt Tel. +49 9503 8099999 (DE) Tel.

  • Page 8: Windows Vista

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.2.3. Windows Vista Click on Start Control Panel. Click on the Network and Sharing Center icon. Click on Broadband Connections Properties. The Local Area Connection Status screen appears. Click on Properties.

  • Page 9: Mac Os 9.X

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.2.4. MAC OS 9.x From the Apple Menu, point to Control Panels and then click TCP/IP. From the Connect via pull-down menu select Ethernet built-in. From the Configure pull-down menu, select Using DHCP Server.

  • Page 10: Mac Os X

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.2.5. MAC OS X From the Apple Menu, select System Preferences... Click on the Network icon in the Internet & Network area. From the Show pull-down menu select Built-in Ethernet.
  • Page 11 Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● On the PPPoE tab, make sure that the Connect using PPPoE check box is NOT activated. Click Apply Now. Close the Network window. Internetagentur Schott GmbH Cent-Hoheneichstr. 11 D-96191 Viereth-Trunstadt Tel.

  • Page 12: Connecting The Iad To Computers, Telephones And Power Supply

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.3. Connecting the IAD to Computers, Telephones and Power Supply 2.3.1. Connecting Computers Use the yellow Ethernet cable. Connect one side to one of the Ethernet ports, and the other side to the PC’s Ethernet interface.

  • Page 13: Connecting The Adsl And Line Cable

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.3.3. Connecting the ADSL and Line Cable 2.3.3.1 Splitter connection (ISDN) not applicable for Internet via Satellite The Splitter / Micro-filter are important for ADSL installation, they help direct high- frequency signals to the ADSL modem &...

  • Page 14: Power Supply

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 2.3.4. Power Supply Plug the supplied power supply to the wall jack and the other side to the IAD. Please note that the plug type may differ according to different countries.

  • Page 15: Quick Start (For Easy Setup)

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 3. Quick Start (for easy setup) Open your browser (e.g. Internet Explorer or Firefox) and type in 192.168.100.1 or http://my.satspeedbox You will be asked to enter a username and password: Enter user as username and user as password.
  • Page 16 Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● Click on “Quick Start” and follow the instructions shown on the screen. This will setup your Internet connection, Wireless LAN and Internet Telephony. For Internet via Satellite it is normally already configured. If you are “satcall” customer too, it is normally already configured for Telephony too.

  • Page 17: Troubleshooting

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 4. Troubleshooting 1. None of the LEDs are on when you turn on the IAD. Check the connection between the adapter and the IAD. If the error persists, you may have a hardware problem.

  • Page 18: Ec Declaration Of Conformity

    Quick Start Guide | SLI-5460 / SLI-5460-I | 2010-03 ● 5. EC Declaration of Conformity The equipment is in conformity with the following European Directives: 1999/5/EC Radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity (R&TTE)
