DELTA® protects property. Saves energy. Creates comfort.
DELTA®-S d -FLEXX
Installation instructions
■
1. Remove old tiles and insulation material. Nails and screws
that visibly penetrate the interior panelling must be covered
with acoustic insulation panels. If none are visible, DELTA®-
S
-FLEXX may be laid out directly on top of the interior
d
panelling.
■
2. Lay out sheets across the rafters in parallel with the gutter,
making sure that there is no tension in the space between
the rafters. Hold DELTA®-S
the rafters.
■
3. Make sure that sheets overlap by 10 cm. Seal overlaps
against draughts with DELTA®-MULTI-BAND.
■
4. Seal any seams (e.g. gutters, flues, roof windows) against
draughts with DELTA®-THAN plus laths or with DELTA®-
KOM-BAND. Openings for pipes should be sealed with
DELTA®-FLEXX-BAND.
■
5. Cut the insulation material to fit the space between the
rafters (+ 1 cm) and lay it on.
Detailed installation instructions for DELTA®-S
available on the internet at www.doerken.de as a pdf file for
you to print out and save.
-FLEXX in place with laths along
d
-FLEXX are
d
1
3
5
■
Draught and
vapour barrier
2
4
■
For retiling
■
Rehabilitation
