- Page 1 SoM-210ES SoM 200-pin Carrier Board User Manual REV. 0.1 Copyright 2010, EMAC, Inc.
-
Page 2: Table Of Contents
Table of Contents Disclaimer ..............................1 SOM-210 Product Summary......................2 Features..................................2 Standard PPC Specifications............................3 SOM-210 Product Details........................4 Jumper Configuration & Connector Descriptions......................4 Power Connectors ................................5 ... -
Page 3: Disclaimer
Disclaimer EMAC Inc. does not assume any liability arising out of the application or use of any of its products or designs. Products designed or distributed by EMAC Inc. are not intended for, or authorized to be used in, applications such as life support systems or for any other use in which the failure of the product could potentially result in personal injury, death or property damage. -
Page 4: Som-210 Product Summary
Touchscreen Interface and Software Controlled Backlight On/Off & Brightness JTAG connector for debug FREE Eclipse IDE with GCC & GDB development tools Linux BSP and SDK available WinCE 6.0 BSP and SDK available ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 5: Standard Ppc Specifications
Operating Temperature: 0 ~ 60° C (32 ~ 140° F) Standard Parts Inventory • SOM-210 Assembly with 4.3” Touchscreen • Molded plastic LCD mounting bracket and standoffs • Three Serial Port cables • CDROM with manuals, schematics, and drivers ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 6: Som-210 Product Details
COM 3 Serial Port HDR4 COM B COM 2 Serial Port HDR5 COM A COM 1 Serial Port HDR6 BDM JTAG SOK1 200 pin SOM Socket SOK2 MicroSD Card Socket SOK3 LCD &Touch Interface Cable Socket ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 7: Power Connectors
JK4 is a standard 5.5mm barrel jack with an inner diameter of 2.1mm with a center V+ connection. This jack allows for easy connection to a wall mount power supply (EMAC part number PER-PWR-00032). The SOM-210’s power input uses a switching regulator and allows a voltage input of +5V DC. - Page 8 Pin Description for 10-Pin Pin Description for DB9 Header Connector 422/485 TX- 422/485 TX- 232 RX, 422/485 TX+ 232 RX, 422/485 TX+ 232 TX, 422/485 RX+ 422/485 RX- 232 TX, 422/485 RX+ 422/485 RX- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc.
-
Page 9: Usb Host Ports
HDR2. This 30-pin dual row header contains GPIO lines, SPI bus, I C bus, A/D lineS, interrupts and power pins. Signal names listed in the table below are the SoM names as defined in the SoM 200 pin specification. ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 10: Real-Time Clock
The SOM-210 is equipped with an external battery for backing up the module’s Real-Time Clock (RTC). Drivers to access the RTC are included in the operating systems. 2.13 Reset The SOM-210 provides a Reset Button (PB1). Pressing this button will cause the system to reset. ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 11: Software
Linux and Windows CE. For more information on these particular Operating Systems, contact EMAC, Inc. For more information on Software, see the module’s User’s Manual. Note: All of the links in this document are subject to change. Please contact EMAC for updated link locations if necessary. ENG-00161-01P-SoM-210ES_User_Manual.doc... -
Page 12: Appendix A: Connector Pinouts
USB_Data- USB_Data+ Power Jack (JK4) Signal Center 5V DC Barrel GND Power Connector (HDR1) Signal 5V DC +Vin MicroSD Socket (SOK2) Signal DAT2 CD/DAT3 VCC (3.3V) SCLK DAT0 DAT1 SD Card Detect -10- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 13: Lcd/Touch/Backlight (Sok3)
LCD/Touch/Backlight (SOK3) Signal Backlight LED+ Backlight LED- Touch X1 Touch Y1 Touch X2 Touch Y2 VDDSEL 3.3V/~2.5V DATA ENABLE VSYNC HSYNC Display ON/~OFF Data CLK -11- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 14: Coma Rs-232 Serial Port (Hdr5)
422/485 TX- 422/485 TX- 232 RX, 422/485 TX+ 232 RX, 422/485 TX+ 232 TX, 422/485 RX+ 422/485 RX- 232 TX, 422/485 RX+ 422/485 RX- 4.10 JTAG Connector (HDR6) Signal Signal VCC (3V) TRST -12- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 15: Misc. I/O (Hdr2)
4.11 Misc. I/O (HDR2) Signal Signal 3.3V CANRX CANTX I2DAT I2CLK RESET_OUT SPI_MI SPI_CK SPI_MO SPI_CS1 SPI_CS0 SPI_CS3/FRM 14 SPI_CS2 AUD_DOUT AUD_MCLK ANALG_05 AUD_SCLK ANALG_07 AUD_DIN ANALG_04 AUD_LRCLK GPIO12 GPIO11 ANALG_06 GPIO13 GPIO15 IRQA 3.3V -13- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 16: Appendix B: Jumper Settings
Pins 2 & 3* Normal Boot from NOR Flash * Default setting Boot Option Selection Jumper Position Setting Pins 1 & 2 Not Used Pins 2 & 3* Not Used * Default Setting -14- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc. -
Page 17: Appendix C: Mechanical Drawing With Dimensions
6 Appendix C: Mechanical drawing with dimensions -15- ENG-00161-01P-SoM-210ES_User_Manual.doc Rev 0.1 © 2010 EMAC, Inc.
