Waterway 600-0111 Installation Instructions

2 1/2" S / 3" SPG SERVICEABLE SWING CHECK VALVE
Straight Body Check Valve (600-0111)
CORRECT
© 2010 Waterway Plastics
INSTALLATION INSTRUCTIONS
5
UPWARD
FLOW
(CORRECT)
2200 East Sturgis Road, Oxnard, CA 93030 • Ph. (805) 981-0262 • Fax (805) 981-9403
www.waterwayplastics.com • waterway@waterwayplastics.com
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
IMPORTANT:
Directional flow of water is essential for proper
function. Serviceable Swing Check Valve is designed for both 2 1/2"
Socket and 3" Spigot pipe.
IMPORTANT:
Prior to installation of valve to fittings, remove lid/
valve assembly (#2) to prevent accidental gluing of components.
CAUTION:
DO NOT allow any glue into the valve body beyond the
pipe stops.

MOUNTING INSTRUCTIONS

The Check Valve can be installed in either horizontal or vertical
plumbing. For vertical plumbing, use only with upward flow.
Follow CORRECT / INCORRECT diagrams below to ensure upward
flow.
INCORRECT
6
DOWNWARD
FLOW
(INCORRECT)
