Daymak Magic Owner's Manual With Assembly Instructions

Children's electric toy car wit remote control function, suitable for 37~96 months, maximum user weight: 40kg, adult assembly required
Hide thumbs Also See for Magic:

Advertisement

Quick Links

Download this manual See also: User Manual
CHILDREN'S
ELECTRIC TOY CAR
With remote control function
Products features may vary
from the picture above.
• Suitable for 37~96 Months
• Maximum user weight: 40kg
• Adult assembly required
OWNER'S MANUAL
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important
information.
Before first time use, charge the battery for at least 4-6 hours.
with Assembly Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the Magic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daymak Magic

Summary of Contents for Daymak Magic

  • Page 1 CHILDREN'S ELECTRIC TOY CAR With remote control function Products features may vary from the picture above. • Suitable for 37~96 Months • Maximum user weight: 40kg • Adult assembly required OWNER'S MANUAL with Assembly Instructions Read and understand this entire manual before using! Please keep this manual for future reference as it contains important information.
  • Page 2 caution WARNING CHOKING HAZARD - Small parts. Not suitable for children under 37 months. Use the vehicle on generally level ground ONLY! WARNING! FOR THE SAFETY OF YOUR CHILD, PLEASE READ ALL WARNINGS AND ASSEMBLY/USE INSTRUCTIONS. KEEP THIS GUIDE FOR FUTURE REFERENCE. •...

  • Page 3: Table Of Contents

    Parts List PART Q’ty (pcs) REMARKS PART NAME Vehiclebody Windshield Seat Steeringcolumn Viewmirror 6pcsforviewmirror,12pcsforsidesupport, Ø4x12roundheadscrew 5pcsforwindshield Lightbar 6pcsforlightbarsupport,8pcsforfront Lightbarsupport axle,8pcsformotorhood Ø4x12flatheadscrew Steeringwheel M5x40machinescrew Placedonthesteeringwheel Ø5nut Placedonthesteeringwheel Rearaxle Gearbox 4pcsplacedonthefrontaxle,2pcs Ø12washer placedontherearalxe. Drivingwheel 2pcsplacedonthefrontaxle,2pcs Ø12locknut placedontherearalxe. Sidesupport Wheel Bushing Placedonthefrontaxle. frontaxleassembly Motorhood Charger Remotecontroller...

  • Page 5: VehicleBody

    Assembly Steps • Your new vehicle requires adult assembly. Please set aside at least 40 minutes for assembly. Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state. Care should be taken in unpacking and assembly of the vehicle.
  • Page 6 ● Remove all the parts from the rear axle. ● Insert the longer end of the rear axle through the hole in the vehicle body. And keep the rear axle match with the vehicle body. Rear axle ● Slide the gear box (standing at back of vehicle body) onto the rear axle.
  • Page 7 Assembly Steps The steering column Ø10 washer should match with the direction gear box Ø10 washer Split pin Steering column Split pin Ø10 washer Steering column ● Turn the vehicle on its side. ● Turn the vehicle on its side. ●...

  • Page 8: Windshield

    Assembly Steps BATTERY INFORMATION Batteries may leak fluids that can cause chemical burn injury or ruin your product. To avoid battery leakage: ● Do not mix old and new batteries. ● Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium). Insert batteries as indicated inside the battery compartment.
  • Page 9 Assembly Steps Fit the tabs on the windshield onto the ● Ø4x12 round head screw slots located at the front of the vehicle. Insert five Ø4x12 round head screws and tighten with a screwdriver. Windshield assembly ● Plug the power connector into the Vehicle connector Vehicle connector anode terminal(red) on battery as shown.

  • Page 10: Seat

    Assembly Steps ● Insert the tabs at the back of the seat M5x12 machine into the slots in the vehicle body. screw ● Tighten two M5x20 machine screws with a screwdriver. Seat Light bar Light bar support assembly Ø4x12 flat head screw Light bar ●...

  • Page 11: Wheel

    How To Operate Your Vehicle WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
  • Page 12 How To Operate Your Vehicle Use Operation Forward-reverse switch Audio input Sound buttons Power switch Foot pedal Volume knob High/low Pedal-R/C Power switch speed switch switch FORWARD 1.Press the “Forward-backward switch” on the “Forward” position. 2.Press the “Foot pedal”, the vehicle drives forward. STOP The vehicle will stop automatically, when your child’s foot remove from the “Foot pedal”.
  • Page 13 HOW TO USE THE REMOTE CONTROLLER ADULT OPERATING REQUIRED LEFT JOY STICK INDICATOR LIGHT RIGHT JOY STICK ON-OFF SWITCH ASSEMBLY 1. Insert the antenna into the controller by tweak the antenna clockwisely; 2. Lift the battery compartment door on the back of the controller and insert two AA(LR6) batteries.

  • Page 14: Charger

    Charging Your Vehicle ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING! • PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or the charger with another brand. Using another battery or charger my cause a fire or explosion. - Do not use the battery or charger for any other product.
  • Page 15 Charging Your Vehicle 1. Open the cover of the socket (the socket is under the rear light bar) 2. Plug the charger port into the input socket. 3. Plug the charger plug into a wall outlet. The battery will begin charging. WARNING! This product with CHARGING PROTECTION: When charging, all the functions will be cut off!
  • Page 16 Troubleshooting Guide ■ PROBLEM: The vehicle does not run PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for a full 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped.
  • Page 17 Troubleshooting Guide ■ PROBLEM: The vehicle does not run very long. POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old.
  • Page 18 Disposal Of Battery Disposal Of Batter y ● Your sealed lead-acid battery must be recycled or disposed of in an environmentally sound manner. ● Do not dispose of your lead-acid battery in a fire. The battery may explode or leak. ●...
