- Page 1 Key Biscayne Installation Manual Models: 59135 Weathered Zinc 59273 Onyx Bengal ©2017 Hunter Fan Co. Weight ±2 lbs: 25.8 lbs (11.7 kg) M3556-01 r030117...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. Here are the tools you’ll need to complete your installation: OPTIONAL If mounting to a support structure, you will also need these tools.
- Page 3 1886 Here is what comes in your box: Hunter Pro Tip: We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Do not discard the hardware bags or mix parts from different bags.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
Follow below if you are using the downrod that came pre-assembled in your box. Need to install a longer or shorter downrod? Check out the guide at the end of this manual. Hunter Pro Tip: The ground wire attached to the downrod is approximately 8 inches. -
Page 7: Wiring The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... -
Page 8: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades: Place each blade between a blade arm and blade medallion. Install three blade screws, found in the hardware bag, to attach the blade medallion to the blade arm. - Page 9 1886 Preparing the Light Fixture Follow these steps to prepare the light fixture for installation. KEEP Fixture Screw Repeat x2 Red Flag Carefully remove the light Remove the pre-installed fixture screw and red Remove and discard the fixture from the light fixture flag from the light kit assembly.
-
Page 10: Installing The Light Fixture
1886 Installing the Light Fixture 3 of 4 Fixture Screw Empty Post Fixture Screw Connect the plugs from the upper and lower switch housings. Make sure to Partially install three fixture screws, found line up the colored markings on the in the hardware bag, into the posts as connectors and that the connectors latch. - Page 11 1886 Installing the Pull Chains The fan pull chain controls the speed: from high to off. Feed the pull chains from the fan switch and the light switch down through the holes in the upper switch housing as shown. Attach the pull chain pendants to the light and fan pull chains.
-
Page 12: Troubleshooting
Noisy Operation • Make sure the blades are properly installed. • Check to see if any of the blades are cracked. If so, Hunter Pro Tip: replace all of the blades. Cleaning the Fan Use soft brushes or cloths to prevent scratching. -
Page 13: Limited Lifetime Warranty
There is no warranty for light bulbs (except where otherwise noted); remote control Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. batteries; fans purchased or installed outside the United States; fans owned by What Does This Warranty Cover? someone other than the original purchaser;...
