Mikasa Sangyo Mvh-306 Service Manual

Reversible compactor

Advertisement

Quick Links

REVERSIBLE COMPACTOR
MVH-306
SERVICE MANUAL
410-00903

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mvh-306 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mikasa Sangyo Mvh-306

  • Page 1 REVERSIBLE COMPACTOR MVH-306 SERVICE MANUAL 410-00903...
  • Page 2 C O N T E N T S 1 .   Tools 2 .   Inspection Procedure 3 .   Engine, Oil and V-belt 4 .   Rules for conducting service work 5 .   Removing and re-mounting 5-1   Removing battery from machine 5-2  ...
  • Page 3 1. TOOLS 1. Wrench 10mm 12mm 13mm 14mm 17mm 19mm 22mm 24mm 27mm Offset wrench/Socket wrench/Adjustable wrench 2. Hexagonal wrench 3/16inch 5mm 8mm 10mm 14mm 3. Plier 4. External snap ring plier/Internal snap ring plier(bent type can be also used) 5.
  • Page 4: Inspection Procedure

    Check for selection of forward/reverse travel. b. Check for speed of forward/reverse travel. (3) Check for abnormal noise during operation. 3.Engine, Oil and V-belt Table 1 INSPECTION PROCEDURE Type MVH-306DS MVH-306GH MVH-306GE Mounted engine Yanmar L70AE Honda GX270 Robin EX270...
  • Page 5 4. RULES FOR CONDUCTING SERVICE WORK 1. In order to avoid deficient reassembly, know normal status of installation before removing or disassembling any part. Level check or replacement of vibrator oil should be carried out on level ground. 2. Each time disassembly is made involving oil seal, gasket, packing, o-ring, lock washer or the like, be sure to replace them with new ones.
  • Page 6 5. REMOVING AND RE-MOUNTING 5-1 Removing and re-mounting the battery (1) Removing the battery 4 pieces of Bolt (15) unscrewed and take off the Battery cover (13). (Photo 1) Battery cover Bolt (15) Photo 1 Nut of the battery terminal (-) (9) removed, disconnect the (-) (1) battery cord.
