RED Hydrogen ONE User Manual

Hide thumbs Also See for Hydrogen ONE:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User Guide

Advertisement

Table of Contents
loading

Related Manuals for RED Hydrogen ONE

Summary of Contents for RED Hydrogen ONE

  • Page 1 User Guide...

  • Page 2: Table Of Contents

    Content Welcome ............................. Getting Started ......................... Initial setup ..........................Setting a SIM card ........................Locking and unlocking the screen ................... Screen and Display ........................The home screen ........................Notifications ..........................Managing Apps ........................Downloading apps ........................Removing apps ........................Deleting apps ..........................
  • Page 3 Tools ............................Calendar ..........................Clock ............................File manager ..........................Phone Settings ........................Switch on or off airplane mode ............................................... Cast your screen ........................Managing the battery ......................Display settings ........................Setting Sound ......................... Viewing the phone storage ..................... Setting the screen unlock method ..................

  • Page 4: Welcome

    Welcome Hello! Welcome to HYDROGEN One. In this manual, you will learn about HYDROGEN One’s basic operation and features. Before reading the contents of this manual, please note: The functions described in this manual are those featured on your phone as it is now.

  • Page 5: Locking And Unlocking The Screen

    Setting the preferred card for mobile data Select which SIM card is preferred for mobile data. Once set, the phone will connect to the mobile network using this card. No mobile data will be consumed via the other SIM card. 1.

  • Page 6: Screen And Display

    Unlocking the screen 1. Press Power/Lock button to turn on the screen. 2. Swipe the screen up to unlock it. • When pattern, PIN, or password unlock has been set up, you need to draw the pattern, enter the PIN or a password to unlock the screen. •...
  • Page 7 Revealing hidden navigation icons In some circumstances, such as when you are taking a photo or viewing an image, the device automatically hides the navigation icons at the bottom of the screen. Swipe up from the bottom of the screen to reveal the hidden navigation icons. Customizing the home screen Setting the wallpaper 1.
  • Page 8 Resizing widgets Only some widgets can be resized. 1. Tap and hold a widget until the phone vibrates. 2. Drag the dots appearing around the widget to adjust its size. 3. Tap any empty space on the screen to finish. Deleting widgets Tap and hold the widget until the phone vibrates, and then drag it onto REMOVE at the top of the screen.

  • Page 9: Notifications

    Notifications Opening the notification bar 1. Depending on the screen mode, you can: • When the screen is unlocked: swipe down from the top of the screen to open the notification bar. • When the screen is locked: tap the Power/Lock button to turn on the screen, and swipe down from the top of the screen to open the notification bar.
  • Page 10 2. Tap the on the right of Do not disturb, or Priority only. You can: • Select Total silence to disable all sounds and vibrations (including alarm clock, music, video and games), while still being able to make phone calls. •...

  • Page 11: Managing Apps

    Managing Apps Downloading apps To protect your phone, please download apps from the Google Play Store on your phone. Downloading apps from other sources may cause unforeseeable damage to your phone. To download apps from the Google Play Store, please visit play.google.com/store/apps to learn how to download and install apps.

  • Page 12: Internet And Sharing

    Internet and Sharing Configuring the network Activating mobile data 1. From the home screen, swipe up to access app list Settings. 2. Tap 3. Tap Network & Internet > Data usage. 4. Switch on Mobile data. Setting the preferred mobile network 1.

  • Page 13: Controlling Data Use

    Using your device as a Wi-Fi hotspot 1. From the home screen, swipe up to access app list. Settings. 2. Tap 3. Tap Network & Internet > Hotspot & tethering. 4. Switch on Wi-Fi hotspot. To change the Wi-Fi hotspot name, network security options and other properties, tap Set up Wi-Fi hotspot.

  • Page 14: Calls And Contacts

    Controlling data usage for apps If you want to limit how much data apps use, you can allow certain apps to connect to the Internet without restrictions while making other apps send and receive data less frequently and only while in use. 1.
  • Page 15 Using your phone during a call Turn on mute so the caller cannot hear sounds from your end. Open the dial pad. Switch between the receiver, speaker or Bluetooth headset. Place the current call on hold. Dial another call. During a phone call, you can swipe up from the bottom of the screen, and tap to leave the call interface without interrupting the call.

  • Page 16: Answering Calls

    Making international phone calls Please first ensure international calling services or international roaming services have been enabled with your carrier. 1. On the home screen, tap Phone. 2. Tap to open the dial pad. 3. Tap and hold the 0 key to insert the + symbol, and then enter the country code, area code, and phone number.

  • Page 17: Setting Call Options

    2. Select a message from the template list. The incoming call will be rejected and the caller will receive the text message. 3. You can pre-set a quick text response in call settings. See Setting a quick text response Setting a quick text response for details. Making a conference call When you need to communicate with multiple parties, you can choose to set up a conference call.

  • Page 18: Contacts

    Contacts Creating a new contact Adding a contact The number of contacts that can be saved on your phone depends on the amount of free space on your phone. The more free space, the more contacts that can be saved. The number of contacts that can be saved on the SIM card depends on its specifications.

  • Page 19: Create A Personal Name Card

    Exporting contact information to a microSD card 1. On the home screen, tap Contacts. 2. Tap > > Export > Export to .vcf file. 3. Enter the name, and tap SAVE. Exporting contact information to a SIM card 1. On the home screen, tap Contacts.

  • Page 20: Messaging

    Linking contacts When there are multiple records for the same contact in the contact list, you can link these records and remove the duplicate entries. Contacts. 1. On the home screen, tap 2. Tap the contact to be linked. 3. Tap > Link. 4.

  • Page 21: Deleting Messages

    • Forward the message: tap and hold the body text of the message then tap • Call back: tap • Save an unknown number: tap > Add contact. Deleting messages Messages. 1. On the home screen, tap 2. Tap the message you want to delete. 3.

  • Page 22: Recording Videos

    Recording videos Camera. 1. In the home screen, tap 2. Tap to switch to video mode. Tap to put the camera in 4V mode. 3. Tap to start recording. When recording, tap to stop recording. Panorama 1. On the home screen, tap Camera.

  • Page 23: Selecting Flash Modes

    : Drag this icon to adjust the ISO. The larger the value, the greater the light sensitivity of the camera. Viewing 4V mode photos and videos RED Player to browse 4V mode photos and videos shot with the device. 1. From the home screen, swipe up to access app list. 2. Tap RED Player.

  • Page 24: Tools

    Default color tone is saved as Look_Default.LXK in Internal storage/DCIM/Favorite Looks. Setting resolution and frame rate You can change the resolution of the front or back camera. When in 2D mode, you can only change the 2D resolution and video frame rate. When in 4V mode, you can only change the 4V mode resolution and frame rate.

  • Page 25: Clock

    Creating an event 1. From the home screen, swipe up to access app list. 2. Tap Calendar. 3. Tap 4. Select event type. 5. Enter information such as the event name. 6. Tap SAVE. Modifying events 1. From the home screen, swipe up to access app list. 2.

  • Page 26: File Manager

    3. Tap 4. Enter the time to count down. 5. Tap after starting the countdown, you can: • Tap to pause the countdown. • Tap “+1:00” to add one minute to the countdown. • Tap RESET to reset the countdown. •...

  • Page 27: Phone Settings

    5. Enter the folder name. 6. Tap OK. Copying a file or folder 1. From the home screen, swipe up to access app list. 2. Tap FileManager. 3. Go to the FOLDER tab, tap and hold the file or folder you want to copy, and then tap 4.

  • Page 28: Nfc

    Settings: Switch airplane mode on or off from 1. From the home screen, swipe up to access app list. 2. Tap Settings. 3. Tap Network & Internet. 4. Turn on or off the Airplane mode switch. Turning NFC on and off: 1.

  • Page 29: Display Settings

    Display settings Setting brightness Your phone enables brightness auto adjusting as default, which can adjust screen brightness automatically according to the environment. You can also adjust the screen brightness by yourself. 1. Swipe down from the top of the screen with two fingers, open the notification panel. 2.

  • Page 30: Setting Sound

    3. Tap Screen Saver. You can: • Set when the screen saver shows: tap When to start, and select an option. • Choose what your screen saver shows: tap Current screen saver, and select an option. • Choose a display mode: Tap Setting sound From the home screen, swipe up to access app list, and tap Settings >...

  • Page 31: Restoring Factory Settings

    • Keep your phone unlocked while it is on you. • Add location where your phone should be unlocked. • Add device to keep your phone unlocked when it is nearby. • Set up facial recognition. Restoring factory settings All data in the phone’s internal storage will be cleared when restoring factory settings. Please back up all your important data and files before restoring the phone to prevent any unnecessary loss.
  • Page 32 TalkBack Turning TalkBack on and off 1. From the home screen, swipe up to access app list. Settings > Accessibility > TalkBack. 2. Tap To turn on TalkBack: 1. Tap the switch. 2. Tap OK. To turn off TalkBack: 1. Tap the switch. You’ll see a green outline. Double tap the switch. 2.
