Summary of Contents for sourcenext pocketalk w
- Page 1 POCKETALK User Manual Please check the web for the latest version of the User Manual https://rd.snxt.jp/12449...
-
Page 2: Table Of Contents
Contents Appearance·······································································02 Specifications·····································································04 Safety Instructions ······························································05 Safety and Handling Instructions············································05 Recycling ··········································································06 Certifications······································································06 Charging ···········································································07 Configuring System Language···············································07 Setting Up Network ·····························································08 Translating ········································································09 Selecting the Languages for Translation ··································09 Viewing History ··································································10 Adjusting Volume ································································10 Checking Battery Level ························································11 Power Management (Sleep Settings)······································... -
Page 3: Appearance
Learn about your portable translation device hardware and how to get started using it. Appearance Speaker Microphone Touchscreen Talk Button Talk Button Microphone... - Page 4 Description of Parts Screen: 2.4 inch touchscreen display Talk Button: Press and hold down this button while speaking into the device. Power Button: ・ Press and hold for 4 seconds to turn the device ON or OFF. ・ Push once to put to Sleep Mode or wake from sleep. SIM Card Slot: Insert a nano-SIM card for mobile data connection.
-
Page 5: Specifications
Specifications Product Name POCKETALK "W" Series Processor ARM Cortex53 Quad-Core 1.3GHz Operating System Custom OS (based on Android OS 8.1) Display Screen Touch Panel / 320 x 240 pixels Battery Rechargeable Lithium Ion Battery Battery Life 2200mAh Speaker Built-in Speakers Speaker Power 1.5 Watts x 2 Microphone... -
Page 6: Safety Instructions
Safety Instructions ・ To avoid injuries due to explosions, fires, or electric shocks, do not attempt to disassemble, repair or modify the device. ・ Avoid leaving the device in hot temperature such as under direct sunlight, inside sun-heated vehicles, or near open fires or stoves. ・... -
Page 7: Recycling
・ If the device is moved suddenly from a cold to warm surrounding, condensation may form on the casing of the device. In such case, before using the device, leave the device in a warm environment until the moisture evaporates. ・... -
Page 8: Charging
Charging Charging the Device Turning ON / OFF the Device Connect the USB charger cable to the Press and hold down the power charger port as shown in the above button (on the top-right part of the illustration. If charging through a device) for 4 seconds. -
Page 9: Setting Up Network
Setting Up Network Settings 100% 通信 Wi-Fi Bluetooth Sleep Settings Text Size Software Update Pocketalk Center 日本語 English ・ Tap on the Setting button at the top-left. ・ Tap on the [3G] or [Wi-Fi] or [Bluetooth] at the top of the screen. ・... -
Page 10: Translating
Translating ご予約をいただいた お客様には、 ドリン クを一杯サービスし ております。 We serve a drink for customers who have made reservations. English 日本語 Speak into the device while holding The translation will be displayed down the button. Let go of the on screen and read out. (Note: button to translate. -
Page 11: Viewing History
We serve a drink We serve a drink Viewing History for customers for customers who have made who have made reservations. reservations. ご予約をいただいたお客様 ご予約をいただいたお客様 には、 ドリンクを一杯サー には、 ドリンクを一杯サー ビスしております。 ビスしております。 ご予約をいただいた ご予約をいただいた Add to Favorite お客様には、 ドリン お客様には、 ドリン Delete クを一杯サービスし... -
Page 12: Checking Battery Level
Checking Battery Level Settings 100% 通信 Wi-Fi Bluetooth Sleep Settings Text Size Software Update Pocketalk Center 日本語 English To check the remaining battery level, tap on the Setting button at the top-left corner of the screen. The battery level is displayed at the top-right corner of the Setting screen. -
Page 13: Changing Text Size
Changing Text Size Settings 100% 通信 Wi-Fi Bluetooth Sleep Settings Text Size Software Update Pocketalk Center 日本語 English To change the text size, tap on the Setting button at the top-left corner of the screen and then tap on the [Text Size] menu to select the font size. Displaying Device Info Settings 100%... -
Page 14: Updating
Updating Settings 100% 通信 Wi-Fi Bluetooth Sleep Settings Text Size Software Update Pocketalk Center 日本語 English To check for the latest updates, tap on the Setting button at the top-left corner of the screen and then tap on the [Software Update] menu. Follow the instructions on screen to update to the latest state. -
Page 15: Factory Reset
Inquiries about the product can be made from the below Customer Support webpage. http://rd.snxt.jp/51991 For inquiries about the after-sales services, please read the "SOURCENEXT Product Support Terms" Found at the below URL. http://rd.snxt.jp/24617 Please note that Customer Support is offered only in Japanese language.
