- Page 1 USER MANUAL BENUTZERHANDBUCH MANUEL UTILISATEUR MANUAL DE USUARIO MANUALE UTENTE MANUAL DO USUÁRIO BRUKSANVISNING ユーザーマニュアル 用户手册 РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ...
- Page 2 TO DOWNLOAD THIS USER MANUAL IN A DIFFERENT LANGUAGE, VISIT WIRALCAM.COM/SUPPORT. WENN SIE DIESES BENUTZERHANDBUCH IN EINER ANDEREN SPRACHE HERUNTERLADEN MÖCHTEN, BESUCHEN SIE WIRALCAM.COM/SUPPORT. POUR TÉLÉCHARGER CE MANUEL DE L’UTILISATEUR DANS UNE AUTRE LANGUE, RENDEZ-VOUS SUR WIRALCAM.COM/SUPPORT. PARA DESCARGAR ESTE MANUAL DE USUARIO EN OTRO IDIOMA, VISITE WIRALCAM.COM/SUPPORT.
- Page 3 BOOM! Thanks for purchasing Wiral LITE believe that this is why you got yourself and welcome to our family! a Wiral LITE, and we believe that this is why you will go out there and create (Please take your brand new Wiral LITE videos never seen before.
- Page 4 4. Do not breach the bounds of privacy. Ask for permission before using Wiral LITE on private property. 5. Do not use the Wiral LITE while under the influence of drugs or alcohol.
- Page 5 6. Do not expose Wiral LITE to water. It is follow these instructions: not waterproof and cannot be used under •...
- Page 6 WHAT’S IN THE BOX END STOP CLIP WIRAL LITE REMOTE CONTROL...
- Page 7 QUICK SETUP Wiral LITE can easily be set up in less than 3 minutes. To learn how to do it, follow the instructions on the next pages. SET UP THE ROPE SYSTEM READ MORE ON PAGE 8-9 MOUNT WIRAL LITE...
- Page 8 SMALL STRAP CARABINER TIGHTENING BUCKLE QUICK REEL™ The Wiral LITE kit comes with the Quick Reel™ that makes it possible to set up the line in just a few minutes. The Quick Reel™ consists of a reel for handling the rope and a tightening strap for connecting and tightening it.
- Page 9 01 UNLOCK QUICK REEL™ 02 ATTACH CARABINER Press rope guide to unlock Quick Place the rope around the first Reel™ and unwind the rope. attachment point, and attach the carabiner to the rope 03 UNWIND ROPE 04 LOCK QUICK REEL™ Pull out the rope and let the reel rotate Lock the Quick Reel™...
- Page 10 The distance can be found in the table on the next page. This will help avoiding Wiral LITE crashing into the attachement points. When the end stop is mounted, it will either derail or stop the unit before it is reaching the end of the line.
- Page 11 The end stop clip should be mounted with a safety zone between itself and the end of the line to avoid Wiral LITE from crashing into the attachment point. The length of the zone will vary with the weight of the camera used.
-
Page 12: Main Unit
LOCK PIN LOCK PIN PULLER ON / OFF BUTTON BATTERY COMPARTMENT BATTERY CONNECTOR CAMERA MOUNT BATTERY PULLEY MAIN UNIT After mounting the line, it is time to prepare the main unit, including the batteries and the camera that is going to be attached. - Page 13 01 CHARGE BATTERY 02 INSERT BATTERY Charge battery using the charger Insert battery and connect it to the included in the kit. Read more power plug. The unit automatically on page 18 - 19. turns on. 03 MOUNT BALL JOINT 04 MOUNT CAMERA Mount the ball joint to be able to point Mount your camera on to the...
-
Page 14: Remote Control
INDICATOR BATTERY COMPARTMENT REMOTE CONTROL Wiral LITE can be operated by using the remote control included in the kit. The remote control is controlling speed and acceleration, setting digital end stops, and giving feedback through six LED lights. Wiral Lite has three different control modes: Normal Mode: Control the speed from 0 to 0.7 m/s (0 - 1.6 mph) - Page 15 02 CONTROL MOVEMENT 01 POWER ON Press the Mode Button to turn on the Rotate the Speed Wheel to move the main unit. Rotating towards the remote control. The Mode LED will yellow arrow, will move the main unit turn on. Hold the same button for 2 seconds to turn off.
- Page 16 CHANGE SPEED MODE 01 CHANGE MODE 02 MODE INDICATION The remote is automatically set to Normal Mode: Mode indicator LED is normal mode when turned on. Change blinking slowly. Sport Mode: Mode indicator LED is modes by pressing the mode button. blinking fast.
- Page 17 SPORT MODE YELLOW DIRECTION MARKS ON ARM SPEED WHEEL MODE INDICATOR When in Sport Mode, the mode indicator will fade quickly in and out. Control the speed from 0 to 9.5 m/s (0 - 31 fps) directly by turning the speed wheel.
- Page 18 TIME LAPSE MODE DIRECTION MARKS ON ARM SPEED WHEEL MOVE / PAUSE BUTTON When in Time Lapse Mode, the mode indicator is continously lit. Control the acceleration by turning the speed wheel. Moving the speed wheel clockwise (towards the yellow arrow) will accelerate the unit towards the side with yellow direction marks.
- Page 19 CHECK BATTERY STATUS To check the battery status of the main unit, hold the play / pause button for 2 seconds. The status will be displayed in the LED below. BATTERY LEVELS MEDIUM FULL 7 - 25 % 25 - 60 % 60 - 100 % LED STATES NORMAL MODE...
- Page 20 BATTERY/CHARGER Wiral LITE is using a 11.1V rechargeable LiPo battery, that can be recharged by using the charger included in the kit. Be sure to read the instructions for use on the next page before using both the battery and...
- Page 21 SAFETY AND DISCLAIMERS 1. Read this whole document (Wiral LITE 8. The user takes the full responsibility of User Manual) before charging and using using this battery. the battery. 2. Never puncture, deform, disassemble, CAUTION shock or short circuit the battery.
- Page 22 AVOID ROPE WEAR 1. Turn on both the remote control and When using Wiral LITE over time, the main unit. rope will wear and tear. To avoid too much damage on the rope, there are 2.
- Page 23 WIRAL LITE FIRMWARE UPDATE We are continously working on improving the performance and functions of Wiral LITE. To be sure your Wiral LITE has the latest features integrated, you should scan the QR code or follow the link below to download the latest update: www.wiralcam.com/firmware...
- Page 24 This content is subject to change. Download the latest version at www.wiralcam.com/support © Wiral Technologies AS. All rights reserved.
