Summary of Contents for Artistic studio Artristic Studio Easel
- Page 1 Artristic Studio Easel User Manual...
-
Page 2: Table Of Contents
Index What You Can Attach, Paint With And Use this Easel For Canvas Stretchers What You Can Attach, Paint With And Use this Easel For........... Depending on the width of the wood used in the frame, and the positions you place the T-Bar arms into the Hub, you can attach canvases from approximately 18cm x 18 cm (7 inches x 7 inches) up to approximately Easel Front view (part names and functions)............ -
Page 3: Easel Front View (Part Names And Functions)
Easel Front view Easel Back view (part names and functions) (part names and functions) Total weight of easel with the 4 T-Bar arms inserted is The rotating centre Hub 10 lbs. (4 ½ Kg.) The Hub Minimum length Tripod legs can fold down to is 24 inches (61 cm) Archways to slide T-Bar arms through... -
Page 4: The Sizes Of Canvas You Can Attach To Your Artristic Easel
The Sizes Of Canvas You Can Attach What The Knobs On The Back to Your Artristic Easel Of The Hub Are For The Hub can be instantly rotated and adjusted in conjunction with the T-Bar arms and the tripod as you paint, bringing any part of your canvas directly to your brush, regardless of your height, whether sitting or standing CAUTION:... -
Page 5: How To Attach The Hub To The Tripod
How To Attach the Hub To The Tripod How To Insert the T-Bar Arms Into the Hub � Hold tripod up- � Turn tripod right side down by two way up. of the legs. Pull � Unlock top leg the legs apart, then clamp and slide out hold the short cen- the bottom leg. -
Page 6: How To Prepare The T-Bar, Hub And Tripod Before Attaching A Canvas
How To Prepare the T-Bar, Hub How To Attach A Canvas To Your Artristic Easel and Tripod Before Attaching A Canvas � Loosen the large centre tube locking-nut and raise the tube up about 20cm (8 inches). � Re-tighten the nut �... - Page 7 How To Attach A Canvas To Your Artristic Easel How To Attach A Canvas To Your Artristic Easel � Continue holding the canvas frame and the T-Bar end to- gether, and with your free hand unlock the left or right T-Bar clamps nearest to the Hub �...
-
Page 8: How To Remove A Canvas In 10 Seconds
How To Attach A Canvas To Your Artristic Easel How To Remove A Canvas In 10 Seconds When removing your canvas there is no need to touch the pointed rods � Rotate and return your canvas to its upright position, tilt it slightly backward and lock in position. -
Page 9: How To Attach 3Mm To 6Mm Thick Art Boards
How to Attach 3mm to 6mm Thick Art Boards How to Attach 3mm to 6mm Thick Art Boards LOCK THIS KNOB � Hold each clear safety cap up against � Adjust tripod height to waist level with � Slide the board edges underneath �... -
Page 10: Attaching White Boards And Canvas Stretchers By Their Outer Edges
Attaching white boards and canvas Attaching white boards and canvas stretchers by their outer edges stretchers by their outer edges WARNING: DO NOT ATTACH VERY HEAVY, LARGE, CHIPBOARD, HARDWOOD OR PLYWOOD BOARDS � Double check that the board is sit- ting flush up against all eight T-Bar shelf end brackets and then start screwing the 8, pointed rods into... -
Page 11: How To Make The Tripod Legs Spread Wider Than Their Pre-Set Distance
How To Make The Tripod Legs Spread How To Make The Tripod Legs Spread Wider Than Their Pre-set Distance Wider Than Their Pre-set Distance The three tripod legs are pre-set in their first position to allow the bottom of them to be spread apart from each other to a distance of 40cm (18 inches). -
Page 12: Convert A Canvas Stretcher Into A Permanent, "Quick Attach" Painting Board
Convert A Canvas Stretcher Into a Permanent, More Ways To Lock The T-bar Arms Into “Quick Attach” Painting Board The Hub And Attach A Canvas This technique is well worth the effort if you use watercolours or pastels and attach painting paper to a board �... -
Page 13: How To Use Your Artristic Tool Kit
How to Use your Artristic Tool Kit How to Use your Artristic Tool Kit � Each Studio easel comes with a pro- � In the outside zippered pocket tective carry bag, a click on adjustable there is a three-piece tool kit Top one to adjust length �... - Page 14 Example of using round or oblong canvas as described on page 3...
- Page 15 www.artristic.com...
