- Page 1 Endless Summer Sport Dolphin Wooden Pools Pool Build Procedure uperior wooden pools, built to the highest quality - at affordable prices. brings water to life...
- Page 2 Timber Materials List For Sport Dolphin Pool...
- Page 3 Essential Tools To Complete Build • Sharp knife • Socket wrench and 19mm, 17mm, 13mm and 10mm socket • Mallet • Batttery drill • No.3 Pozi bit • 6mm drill bit • 12mm Auger bit (supplied with pool kit) Socket Wrench Sharp Knife Mallet 19mm...
- Page 5 Nuts, Bolts & Screws M10 x 40mm Coach Screw - SPGP13 M10 Black Bolt Cap - SPGP06 Used On Base For Upright Supports M10 x 80mm Coach Bolt - SPGP15 M6 x 40mm Coach Screw - SPGP12 M10 Nut - SPGP16 M6 Black Bolt Cap - SPGP05 Used On Steel Base Corner Plates M10 Washer - SPGP11...
- Page 7 Starting The Build Process 12mm Nuts & Washers STEP 1 -Lay out the eight 200mm x 50mm base timbers STEP 2 -Fit the base corners using the 12mm on the area where the pool is to be situated. nuts and washers. Please note: According to the time of the year and weather conditions, the timber can ex- pand and become tight when fitting the base corner brackets.
- Page 8 Centre of base timber STEP 7 - Position the remaining shoes at the centre of the STEP 8 -The skimmer panel has two steel shoes. Use the skimmer support timber to help centre and position the steel short base timbers as shown. Do not fix at this stage. shoes.
- Page 9 Row 8 Row 7 Return Inlets Row 6 Row 5 Row 4 Row 3 Low Suction Row 2 Tongue On Top Row 1 STEP 13 - Tap the timbers down gently using a scrap STEP 14 - When preparing the pool please remember to place piece of wood.
- Page 10 Fast Lane Fittings STEP 19 - Fit the return inlet, lower suction fittings and the STEP 20 - Make sure gaskets have been fitted and holes Fast Lane fittings. are aligned. STEP 21 - Attach the return inlet pipe and valve section to STEP 22 - The skimmer, return inlet and low the threaded unions protruding through the pool wall.
- Page 11 STEP 25 - Place the upright posts in the steel shoes with STEP 26 - Align the upright posts with the wall holes. the holes facing outwards. Do not fix the uprights in the shoes at this stage. STEP 27 - Loosely attach the 96mm x 96mm timbers to STEP 28 - Drill holes through the timber and pool wall the long bolts protruding through the posts.
- Page 12 STEP 31 - Using straps around the ring beam whilst fitting STEP 32 - View of the two corner bolts from above. makes the job easier. STEP 33 - Align the corners and insert the 100mm STEP 34 - Lay out the steel inner ring beam round the pool stainless steel screws as shown top and bottom making top.
- Page 13 STEP 37 - Screw the metal ring beam to the wooden ring STEP 38 - Check that all the posts are upright. Tap the base beam using No12 x 2.5 screws SPGP38 and washers left or right as neccessary using the mallet. SPGP39.
- Page 14 During pool operation the pump Port can be used to drain the pool. Close valve off valve should be left in the open first, remove plug and position. Only close valve when connect pipe and open pump is switched off. valve to drain.
- Page 15 STEP 49 - Cut the foam around the suction and return fittings. STEP 50 - Completed foam barrier STEP 51 - Lay the liner in the pool as close to the position that the STEP 52 - Start placing the liner in the top groove of the liner will be finally fitted.
- Page 16 Do Not Cut The Hole To Big. STEP 55 - When the water reaches the lower suction point, cut STEP 56 - Fit the plastic clamp plate with the screws a small cross by feeling the centre of the hole and pressing the provided.
- Page 17 STEP 61 - Remove black glands and threaded rods STEP 62 - Fittings for Fast Lane hose STEP 63 - Silicone white fitting in to the Fast Lane fitting STEP 64 - Glue grey PVC fittings into white fitting using glue provided STEP 65 - Silicone black Fast Lane fitting into the STEP 66 - Attach the bar to the Fast Lane.
- Page 18 STEP 67 -Squirt silicone into the hole for threaded rods STEP 68 - Push threaded rods through the hole, leave nut and washer on the rod, cut a small incision in the liner for the rod to go through. STEP 69 - Lower the Fast Lane into the pool and attach to STEP 70 - Thread the hose through the Fast Lane fittings.
- Page 19 STEP 73 - Go around the pool gently tightening the nuts and STEP 74 - While the pool is filling with water, place the checking that the pool timbers are level. timber top surround into position around the pool. Do Not over tighten. STEP 75 - Line up all 8 corners with an even overlap of STEP 76 - When all of the top timbers are in position start the timber.
- Page 20 STEP 79 - Place the flange bracket so that the two holes STEP 80 - Drill 6mm pilot holes through the timber. shown are over the 96mm x 96mm timber under the top. Tighten down with M10 x 100mm coach screws. STEP 81 - Place the stainless steel covers and then STEP 82 - Screw in the two eye screws into the top of the assemble and fit the steps.
- Page 21 Corner Skimmer Panel Top Log 11 + 1/2 10 + 1/2 Skimmer 9 + 1/2 8 + 1/2 7 + 1/2 6 + 1/2 Return Outlets 5 + 1/2 4 + 1/2 3 + 1/2 2 + 1/2 Low Suctiom 1 + 1/2 Base 1/2 Log End Skimmer Panel...
-
Page 22: Optional Extras
Walu Woodstar Above Ground Pool Cover Elecro Heaters This safety cover is easy to install and Electric heaters suitable for use operate and is available in four colours. on your wooden pool. Contact your Certikin stockist for prices and availablity. - Page 24 Enless Summer Wooden Pools Certikin International Limited Unit 9, Witan Park, Avenue 2, Station Lane Industrial Estate Witney, Oxfordshire OX28 4FJ Tel: 01993 778855 Fax: 01993 778620 www.certikin.co.uk / www.endlessssummer.co.uk...
