- Page 1 CK502300TX BARROW CONSOLE For assistance with assembly, contact. Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO:13876 Top supports up to Shelf supports up to...
- Page 2 CK502300TX BARROW CONSOLE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. 2PCS 12PCS Top Frame Shelf Frames...
- Page 3 CK502300TX BARROW CONSOLE Assembly Instructions Step 1 Unit assembly should begin with parts turned upside down for Step 1. Attach Screws (A) to Top Frame (1) and twist Screws (A) clockwise to tighten them as shown. Screw Supports (3) onto Screws (A) already attached to Top Frame (1) from Figure.
- Page 4 Step 3 Attach Supports (3) to Screws (A) and tighten by hand. Figure 3 Step 4 Attach Screws (A) to Supports (3) and then, attach Shelf Frame (2) to Supports (3) connecting with Screws (A) as shown. Figure 4...
- Page 5 Step 5: Attach Legs (4) to Screws (A) and tighten by hand. Attach Levelers (B) to Legs (4) as shown. Figure 5 Step 6 Turn the assembled parts upright. Attach Glass Pads (C) onto brackets of Top Frame (1) and Shelf Frames (2).
- Page 6 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
