Read these instructions before using the machine.
Operating instructions (ENG)
MODELS:
TD12V120
1.007-082.0
Advertisement
Table of Contents
Summary of Contents for Kärcher PS 4/7 BP
- Page 1 Operating instructions (ENG) MODELS: TD12V120 1.007-082.0 WARNING: This product and accessories may contain a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. For more information about this regulation: www.P65Warnings.ca.gov 86390170-L 02/07/18 Read these instructions before using the machine.
-
Page 2: Machine Data Label
Thank you for choosing our product. Warranty registration is quick and easy. Your registration will allow us to serve you better over the lifetime of the product. To register your product go to: http://warranty.karcherna.com/warrantyregistration.aspx For customer assistance: 1-800-444-7654 86390170 - KARCHER PS 4/7 BP... -
Page 3: Table Of Contents
Suggested Spare Parts..... 34 Serial Numbers ......35 86390170 - KARCHER PS 4/7 BP... -
Page 4: How To Use This Manual
KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. NOTE: The manual part number is located on the lower left corner of the front cover. 86390170 - KARCHER PS 4/7 BP... -
Page 5: Safety
Do not spray anything that is flammable. This misting system is specifically designed for use with disinfectants that are EPA approved for misting. Read and understand the EPA label for proper use and personal protection. READ AND SAVE THESE INSTRUCTIONS 86390170 - KARCHER PS 4/7 BP... - Page 6 Le système de brumisation est conçu spécifiquement pour être utilisé avec des désinfectants approuvés par l'EPA pour la brumisation. Lire et comprendre l'étiquette EPA pour une utilisation appropriée et la protection personnelle. CONSERVER CES INSTRUCTIONS 86390170 - KARCHER PS 4/7 BP...
-
Page 7: Hazard Intensity Level
In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use only manufacturer approved replacement parts. 86390170 - KARCHER PS 4/7 BP... - Page 8 LORS DE L'ENTRETIEN DE LA MACHINE : Éviter les parties amovibles. Ne pas porter de vêtements amples, tels que des vestes, des chemises ou des vêtements avec manches lors de l'utilisation de la machine. Utiliser les pièces détachées homologuées. 86390170 - KARCHER PS 4/7 BP...
- Page 9 Notes 86390170 - KARCHER PS 4/7 BP...
-
Page 10: Operation
Operation Technical Details ITEM MEASURE Weight 32LB 14.5KG Height 39.5” 1003MM Compact size for transport and storage 22.5” 571.5MM Wheels 3” 76MM Length 19” 482.6MM Width 13.5” 343MM Length Width Height 86390170 - KARCHER PS 4/7 BP... -
Page 11: Controls/Components
Rincer à fond le système avec de l'eau avant d'y verser un nouveau produit. Machine is not designed to be sat upon or ridden. L'appareil n'est pas conçu pour s'y asseoir ou être conduit. 86390170 - KARCHER PS 4/7 BP... -
Page 12: Pre-Run Inspection
3. Remove reservoir cap and dump chemical by turning machine over. 4. Fill reservoir with warm water. (0.5-1 Gallon) 5. Turn machine back on. 6. Open spray valve until spray stops. To speed up process, remove nozzle. 86390170 - KARCHER PS 4/7 BP... -
Page 13: Maintenance
2. Clean nozzle with warm water and a soft bristled brush. A stainless steel compatible cleaner may also be used. 3. Reverse steps to re-assemble NOTE: Make sure to hold spray gun valve open (Squeeze gun trigger) during disassembly and re- assembly. 86390170 - KARCHER PS 4/7 BP... -
Page 14: Pump Replacement
8. Connect new battery to connectors on wires. Be sure to connect the black wire connector to the negative battery terminal. 9. Install new battery in machine. 10. Replace battery access panel and screws. 11. Set machine back upright. 12. Turn machine on to test function. 13. Charge battery to test function. 86390170 - KARCHER PS 4/7 BP... -
Page 15: Troubleshooting
Clogged filter Inspect filter for debris, clean if necessary Remove nozzle and open valve until air passes Air trapped in pump through pump Pump won’t turn off Out of chemical Put more chemical in tank 86390170 - KARCHER PS 4/7 BP... - Page 16 Notes 86390170 - KARCHER PS 4/7 BP...
-
Page 17: Parts
Parts PARTS 86390170 - KARCHER PS 4/7 BP... -
Page 18: Base
Base 86390170 - KARCHER PS 4/7 BP... - Page 19 Base SERIAL NO. PART NO. DESCRIPTION NOTES FROM 86379830 CASTER, 3"OD, GRAY 86379820 SPACER, 3/8INX1-1/2ODX3/8THK 86379850 PLATE, BASE, ASM 86005630 NUT HEX NYL LOC-THIN SS 3/8-16 86379840 COVER, NUT, 3/8, SATIN CHROME 86390170 - KARCHER PS 4/7 BP...
-
Page 20: Battery And Bracket
Battery and Bracket 86390170 - KARCHER PS 4/7 BP... - Page 21 86379800 BATTERY, AGM, 12V, 10.8 AH 86379860 BRKT ASSY, PUMP MOUNT 86391240 BRKT, BATTERY BRACE 87067310 BUSHING, 3/4" SNAP HEYCO P/N 2096 86274290 SCREW, 10-32 X .375 PHPNHMS SS 86390480 CHARGER, BATTERY, 12V, CTEK 86390170 - KARCHER PS 4/7 BP...
-
Page 22: Accumulator And Pump
Accumulator and Pump Handle Mount From Tank Sprayer 86390170 - KARCHER PS 4/7 BP... - Page 23 TUBE 1/4" OD X 12.5, BLACK 86010800 WASHER .2IDX.500 BLK SS 86005810 NUT 1/4-20 HEX NYLOCK SS 86273920 SCREW 1/4-20 X 1.75 PPHMS SS 86391260 REDUCER, 1/4 X 3/8 NPTF 86264930 CABLE TIE, 3.5" UL/CSA 86390170 - KARCHER PS 4/7 BP...
-
Page 24: Tank
Tank 86390170 - KARCHER PS 4/7 BP... - Page 25 GRIP BAND, BOTTLE 86387720 GASKET, SOLUTION BOTTLE 86270990 NUT 10-32 HEX NYLOCK SS 86384280 BRKT, CLAMP, BOTTLE 86390250 CAP, ASM, 6.5LB, CHECK VALVE 86007970 STRAINER 3/8 IN. NPT 60 MESH *See Serial Number Page 86390170 - KARCHER PS 4/7 BP...
-
Page 26: Shell
Shell 86390170 - KARCHER PS 4/7 BP... - Page 27 Shell SERIAL NO. PART NO. DESCRIPTION NOTES FROM 86379780 PLATE, COVER, LH 86379980 PLATE, TOP, RETAINER ASM 86379770 PLATE, COVER, RH 86274290 SCREW, 10-32 X .375 PHPNHMS SS 86390170 - KARCHER PS 4/7 BP...
-
Page 28: Handle
Handle 86390170 - KARCHER PS 4/7 BP... - Page 29 HANDLE, TUBE, .875 OD 86390080 BUTTON, SNAP, SINGLE, .36DIA 86277490 SCR, 6-32 X 1.375 PHPNHMS SS 86217220 CORD HOOK, LOWER 86014810 NUT, 6-32 ACORN SS 86004070 GRIP, POLISHER HANDLE 86391270 SPLIT LOCK COLLAR, 1" TO 7/8" 86390170 - KARCHER PS 4/7 BP...
-
Page 30: Sprayer
Sprayer 86390170 - KARCHER PS 4/7 BP... - Page 31 Sprayer SERIAL NO. PART NO. DESCRIPTION NOTES FROM INCLUDES 86400010 KIT, SPRAY GUN, PS 4/7 BP ITEMS 2-7 86391200 WASHER, GUN, UNIJET NOZZLE 86391680 NOZZLE VOLUME SPACER 86391190 ADAPTER, UNIJET 1/4 TURN 86390140 GASKET, NOZZLE, SEAT 86390150 NOZZLE, TPU400033-SS 86391180...
-
Page 32: Wiring Diagram
Wiring Diagram Charging Port RED/BLACK BLACK On/Off Button BLACK Battery Motor 86390170 - KARCHER PS 4/7 BP... - Page 33 Wiring Diagram PART SERIAL NO. DESCRIPTION NOTES FROM Can be substituted with 86390580 WIRE, INLINE FUSE, CTEK, 5AMP standard automotive 5 Amp fuse 86390170 - KARCHER PS 4/7 BP...
-
Page 34: Suggested Spare Parts
BATTERY, AGM, 12V, 10.8 AH 86007970 STRAINER 3/8 IN. NPT 60 MESH 86390250 CAP, ASM, 6.5LB, CHECK VALVE 86390560 GUN, ASM, 1/4 TURN NOZZLE 86390150 NOZZLE, TPU400033-SS 86390040 HOSE, 1/4X1/4MPT, RETRACTABLE 86390480 CHARGER, BATTERY, 12V, CTEK 86390170 - KARCHER PS 4/7 BP... -
Page 35: Serial Numbers
Serial Numbers REF. MODEL: SERIAL # 10070820000561 86390170 - KARCHER PS 4/7 BP...
