MR4S Spare Parts and Modification Instruction
Proof of Change MR4S Spare Parts:
20181008 MR 4S 25 SCR1 changed from M4x30 to M4x32, STP-CD removed
20181008 MR 30 4S added
20180301 Change of Spare Parts added
20171211 Document generated
20171211 Structure of Document generated
Date
Proof of Change MR4S Modification Instruction:
20180219 Change of Spare Parts moved to MR4S Spare Parts
20180219 Change of Spare Parts added
20180202 Document generated
20180201 Structure of English Document generated
Date
G:\DEML\E_Entwicklung(TD)\EDOK_Dokumentation\EDOK_MR4S\EDOK_MR4S_Dokumente\EDOK_MR4S_Dokumente_Umbau_Ersatzteile_E_V02.docx
Tel.
++49 (0)7081 782-0
Fax
++49 (0)7081 782-124
Internet
www.schneeberger.com
Text of the Amendment
Text of the Amendment
QFO_#00132
DEML/FF
DEML/FF
DEML/FF
DEML/FF
HTMLGen
DEML/FF
DEML/FF
DEML/FF
HTMLGen
DEML/TD
DEML/TD
DEML/TD
DEML/TD
Author
Release
DEML/TD
DEML/TD
DEML/TD
Author
Release
Seite 1/25
Advertisement
Table of Contents
Summary of Contents for Schneeberger MR4S
- Page 1 20171211 Structure of Document generated HTMLGen Date Text of the Amendment Author Release Proof of Change MR4S Modification Instruction: 20180219 Change of Spare Parts moved to MR4S Spare Parts DEML/FF DEML/TD 20180219 Change of Spare Parts added DEML/FF DEML/TD 20180202 Document generated...
-
Page 2: Table Of Contents
QFO_#00132 Deutschland Inhalt MR4S Spare Parts ....................... 3 Introduction Spare Parts MR4S ................3 Front Plate and Front Panel ..................4 Front Plate, Front Panel and Metal Wiper ............... 6 Front Plate, Front Panel and Additional Wiper ............8 Front Plate, Front Panel, Additional Wiper and Metal Wiper ......... 10 Front Plate, Front Panel and Lubrication Plate ............ -
Page 3: Mr4S Spare Parts
QFO_#00132 Deutschland MR4S Spare Parts Introduction Spare Parts MR4S This chapter gives an overview of all MR4S spare parts. These are related to the added accessories. Combinations of accessories: front plate (STP)+ front panel (FRB) + metal wiper (ASM) ... -
Page 4: Front Plate And Front Panel
QFO_#00132 Deutschland Front Plate and Front Panel MR4S carriage MR4S carriage with AMSA MR4S carriage with AMSABS 3B 3B/AMSD 3B FRB: front panel FRB: front panel FRB: front panel QAS: cross wiper QAS: cross wiper ... - Page 5 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 856 580 106 072 580 106 480 580 106 076 580 106 765...
-
Page 6: Front Plate, Front Panel And Metal Wiper
QFO_#00132 Deutschland Front Plate, Front Panel and Metal Wiper MR4S carriage with metal MR4S carriage with AMSA MR4S carriage with AMSABS 3B and wiper (ASM) 3B/AMSD 3B and metal wiper metal wiper (ASM) (ASM) ASM: metal wiper * ... - Page 7 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 856 580 106 072 580 106 480 580 106 076 580 106 765...
-
Page 8: Front Plate, Front Panel And Additional Wiper
QFO_#00132 Deutschland Front Plate, Front Panel and Additional Wiper MR4S carriage with additional MR4S carriage with AMSA MR4S carriage with AMSABS 3B and wiper (ZCV) 3B/AMSD 3B and additional additional wiper (ZCV) wiper (ZCV) ZCV: additional wiper ZCV: additional wiper ... - Page 9 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 856 580 106 072 580 106 480 580 106 076 580 106 765...
-
Page 10: Front Plate, Front Panel, Additional Wiper And Metal Wiper
Deutschland Front Plate, Front Panel, Additional Wiper and Metal Wiper MR4S carriage with, MR4S carriage with AMSA MR4S carriage with AMSABS 3B and additional wiper (ZCV) and 3B/AMSD 3B and additional additional wiper (ZCV) and metal wiper wiper (ZCV) and metal wiper... - Page 11 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 856 580 106 072 580 106 480 580 106 076 580 106 765...
-
Page 12: Front Plate, Front Panel And Lubrication Plate
Internet www.schneeberger.com QFO_#00132 Deutschland Front Plate, Front Panel and Lubrication Plate MR4S carriage with lubrication MR4S carriage with AMSA 3B/AMSD MR4S carriage with AMSABS 3B plate (SPL) 3B and lubrication plate (SPL) and lubrication plate (SPL) SPL: lubrication plate ... - Page 13 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 072 580 106 480 580 106 076 580 106 765 (applies also to...
-
Page 14: Front Plate, Front Panel, Lubrication Plate And Metal Wiper
Deutschland Front Plate, Front Panel, Lubrication Plate and Metal Wiper MR4S carriage with MR4S carriage with AMSA MR4S carriage with AMSABS 3B and lubrication plate (SPL) and 3B/AMSD 3B and lubrication plate lubrication plate (SPL) and metal metal wiper (ASM) - Page 15 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 072 580 106 480 580 106 076 580 106 765 (applies also to CD)
-
Page 16: Front Plate, Front Panel, Lubrication Plate And Additional Wiper
QFO_#00132 Deutschland Front Plate, Front Panel, Lubrication Plate and Additional Wiper MR4S carriage with MR4S carriage with AMSA MR4S carriage with AMSABS 3B and lubrication plate (SPL) and 3B/AMSD 3B and lubrication lubrication plate (SPL) and additional additional wiper (ZCV) - Page 17 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 072 580 106 480 580 106 076 580 106 765 (applies also to...
-
Page 18: Front Plate, Front Panel, Lubrication Plate, Additional Wiper And Metal Wiper
Front Plate, Front Panel, Lubrication Plate, Additional Wiper and Metal Wiper MR4S carriage with MR4S carriage with AMSA MR4S carriage with AMSABS 3B and lubrication plate (SPL), 3B/AMSD 3B and lubrication plate lubrication plate (SPL), additional additional wiper (ZCV) and... - Page 19 Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Spare Part 25 STP-Z 580 106 510 580 106 072 580 106 480 580 106 076 580 106 765 (applies also to...
-
Page 20: Change Of Spare Parts
Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland 1.10 Change of Spare Parts Spare Parts: front plate(STP) cross wiper(QAS) front panel (FRB) lubrication plate (SPL) additional wiper (ZCV) ... -
Page 21: Change Of Cross Wiper
Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland 1.10.1 Change of Cross Wiper The QAS and the ZCV have to be controlled and changed if needed. Steps to change the QAS: 1. -
Page 22: Mr4S Modification Instruction
Deutschland MR4S Modification Instruction In this modification instruction, the permissible modifications of the product "MR4S" will be named and described. If one or both front plates of the carriage will be disassembled, the modification should take place on a assembly rail. -
Page 23: Modification From Standard To Separate Lubricant Distribution
Schneeberger GmbH Tel. ++49 (0)7081 782-0 Gräfenau ++49 (0)7081 782-124 D-75339 Höfen / Enz Internet www.schneeberger.com QFO_#00132 Deutschland Modification from Standard to Separate Lubricant Distribution The complete STP contains a red housing and a gray or black Inlet (characterized with a black or grey pin; see figure). -
Page 24: Modification Of The Lubrication Connections
The following figure shows the lubrication connections for standard and separate lubrication distribution: Lubrication Options Lubrication Options Standard Lubricant Distribution Separate Lubricant Distribution Only the following modifications of the lubrication options are allowed. Other lubrication options were only made at the Schneeberger GmbH. G:\DEML\E_Entwicklung(TD)\EDOK_Dokumentation\EDOK_MR4S\EDOK_MR4S_Dokumente\EDOK_MR4S_Dokumente_Umbau_Ersatzteile_E_V02.docx Seite 24/25... -
Page 25: Standard Lubricant Distribution
1. push the carriage on an assembly rail 2. remove front plate from carriage 3. drill the connection center top under consideration of the work directive 4. insert O-ring (6,75x1,78; exception MR4S 65: 6,5x2) 5. assemble front plate 2.3.2 Separate Lubricant Distribution The initial state of the following modifications is a carriage with standard lubricant distribution and the lubrication option S99, which means that all lubricant connections are closed with grub screws.
