VI-1TC
V Inground is a high power and robust outdoor luminaries. With cutting edge LED technology, IP67 rated and
drive over resistant construction, the V Inground is specially designed for illuminating walkways and
landscape.
1.
Attention:
- Do not install the
fixture
- Do not allow anything to rest on the fixture.
- Do not install the
fixture
- Do not install the fixture in dirty, dusty location.
- Do not looking directly into the LED light beam at close range.
- Operate only in places where the sufficient air flow is present.
2. Technical specifications:
Item
Max. Input Current
Input Voltage
Power Consumption
Compatible Power Supply
LED Emitter
Number of LEDs
LED Life Expectancy
Beam Angle
Available LED Colors
IP Rated
Power/Data Cable
Size
Weight
User manual
V Inground Series
near high inflammable liquids or materials.
near the naked flames.
VI-1TC
350mA
DC 48V
3.3W
V Power 60, V Power 120, V Power 240, V Power 600
3W
1 x Tri-color
50,000hrs
25°, 40°
RGB(3 in1)
IP 68
Ø45 x 82mm
0.4kg
VI-6
VI-6
350mA
DC 48V
6.5W
1W
2R, 2G, 2B
50,000hrs
15°, 25°
RGB
IP 67
1.5m, 24AWG x 4P Cat.5e Cable
Ø119 x 131mm
0.8kg
VI-12
VI-12
350mA
DC 48V
13.1W
1W
4R, 4G, 4B
50,000hrs
15°, 25°
RGB
IP 67
Ø 181 x 97mm
2.0kg
Advertisement
Table of Contents
Summary of Contents for VISIO VI-1TC
- Page 1 User manual V Inground Series VI-1TC VI-6 VI-12 V Inground is a high power and robust outdoor luminaries. With cutting edge LED technology, IP67 rated and drive over resistant construction, the V Inground is specially designed for illuminating walkways and landscape.
- Page 2 3. Installation V Inground unit should be connected to the V Power driver. See V Power 60( or V Power 120, V Power 240, V Power 600) user manual for full details of mains power requirement, built-in programs and DMX operation.
