OWNER'S MANUAL
SAFETY
Important safety instructions for using the INCRA Miter5000
Before using the INCRA Miter5000, read and follow all of the instructions and safety information in this owner's manual.
When using the INCRA Miter5000 in conjunction with any other tool, first read and follow all instructions and safety information
°
in that tool's owner's manual.
Never let the saw blade come in contact with the aluminum or steel components of the INCRA Miter5000.
°
Before making any cut, always make sure that the Miter5000's Sled Base Right is locked securely in the right hand miter slot.
°
When using the INCRA Miter5000, always keep your hands clear of the saw blade and the line of cut.
°
Always turn off the power and make sure that the saw blade comes to a complete stop before changing the setting of any part of the
°
INCRA Miter5000.
Always securely tighten the large black clamping knob before starting any cut.
°
Wear safety glasses, hearing protection, and follow all normal shop safety practices.
°
After making any adjustments to the miter angle or fence position of your INCRA Miter5000, always verify safe clearance between
°
the blade and fence before turning on the saw.
After making any adjustments to the fence position on the INCRA Miter5000, always make sure that the four socket head screws on
°
the fence mounting bracket and the outboard fence lock are securely tightened.
When using the INCRA Flip Shop Stop to position a piece for a cut, always hold or otherwise clamp the board between the stop and
°
the blade.
Manufactured by Taylor Design Group, Inc. P.O. BOX 810262 Dallas, TX 75381
w w w . i n c r a . c o m
by
Before using the INCRA
Miter5000, read and follow
all of the instructions and
safety information in this
owner's manual.
©2016 by Taylor Design Group, Inc. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Miter 5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Incra Miter 5000

  • Page 1 ° the fence mounting bracket and the outboard fence lock are securely tightened. When using the INCRA Flip Shop Stop to position a piece for a cut, always hold or otherwise clamp the board between the stop and ° the blade.

  • Page 2: Parts List

    3. Pivot shoulder bolt If you have a left hand blade tilt table saw, the Miter 5000 can be converted for use on the right side of the blade. Just follow the instructions below.
  • Page 3 INCRA MITER5000 OWNER’S MANUAL Fig. 4 Adjust Steel Miter Bar ASSEMBLY Adjust each of the (5) white expansion disks 1. Adjust the Steel Miter Bar Open hardware pack C-07 and using the supplied 3/32” Fig. 5 Attach T-Clip hex key, adjust the miter bar at each of the (5) expansion...
  • Page 4 The overlap allows fine-tuning the scale from one end to the other to agree with the high degree of accuracy provided by the INCRA saw toothed positioning racks. As they are slid 1/4-20x3/8” socket into the scale slot on the fence, the ends are overlapped...
  • Page 5 This one time calibration prepares your INCRA Miter5000 for work. Just remember that the accuracy of the INCRA Miter5000 at any subsequent setting is depen- dent upon the accuracy of your initial 90° calibration. After completing the Calibration and Operation sections of this...

  • Page 6: Operation

    OPERATION 1st: Loosen large - CHANGING ANGLE SETTINGS clamping knob 2nd: Loosen front The dual actuator design of the INCRA Miter5000 provides actuator thumb- two levels of adjustment. The front actuator is used for screw and pivot tooth away from coarse adjustments (5°), while the rear actuator is used for...

  • Page 7: Calibration And Operation

    FLIP FENCE AND FLIP SHOP STOP - CALIBRATION AND OPERATION As you look at your new INCRA Flip Shop Stop and Flip Fence for the first time you will see an interesting detail. The front face of the fence uses a tongue and groove arrangement to accept a mating feature on the flip arms, Fig.
