Summary of Contents for IntelliScanner IS90
- Page 2 LEGAL NOTICE IntelliScanner Scanabout (part # IS90). © 2012 Apparent Corporation. Other trademarks are the property of their respective owners – no endorsements by third-party trademark holders are implied. Product includes parts and accessories which may represent a choking hazard to small children. Revision 2012-08. http://www.intelliscanner.com.
-
Page 3: Table Of Contents
HI, I’M INTELLISCANNER! Button LED Indicator Mini USB port (w/ protective cover) Scanning Aperture IntelliScanner Scanabout is a Bluetooth® wireless barcode scanner you can use with your Mac, PC, iPhone, or iPad. Introduction................4 Beeps and LED Guide..............6 Setup..................8 Numeric Entry................12 General Controls...............15 Timeout/Reading Mode............16... -
Page 4: Introduction
IntelliScanner Mini USB Your Computer’s USB Port Charge your IntelliScanner with the included cable. Connect one end to the mini USB port (under the flap), and the other end to your computer. The red light turns off when fully charged. - Page 5 HOW TO SCAN Press and hold down the button for a second to turn on IntelliScanner – you’ll hear a beep when the scanner turns on. To scan a barcode, hold the button down while aiming from a short distance. Be sure the red scanning beam fully crosses the barcode.
-
Page 6: Beeps And Led Guide
BEEPS Single Long Beep Power up Single Beep Scanned successfully Two beeps Bluetooth® connection established Three beeps No Bluetooth® connection Three short beeps Scanned successfully, no device connected Five beeps Low power LED INDICATORS Standby or Off Flashing Green Disconnected or Discoverable Green for 2 sec Scanned Successfully Flashing Red... - Page 7 If you want to use the included IntelliScanner apps on your computer, you’ll find the activation codes and download link attached to the inside of your scanner’s box.
-
Page 8: Setup
PAIRING Step 2: On your iOS device, open Settings app > General > Bluetooth. Ensure Bluetooth is on, then select “IntelliScanner” from the list. Step 3: You’ll be asked to enter a PIN to authenticate your connection. “Type” the pincode displayed by your iOS device by following the... - Page 9 Step 3 (cont): From this point forward, your two devices are paired – that is, when you turn on your IntelliScanner within range of your device, they’ll automatically connect and you can immediately start scanning. You can also prompt a manual connection by tapping the scanner on your iOS device.
- Page 10 Skip this and just close the window. Once completed, your two devices are paired – that is, when you turn on your IntelliScanner, it’ll automatically connect. You can can also prompt a manual connection on your computer.
- Page 11 PINCODE SETUP If your device is asking you to enter a pincode, follow these steps: Step 1: Scan the following barcode: Step 2: Scan the pincode your device is asking you to type on the next page, then immediately return to this page to scan the last two pairing barcodes below.
-
Page 12: Numeric Entry
PINCODE NUMERIC ENTRY... - Page 13 After entering your pincode, turn back a page to finish setup.
- Page 14 ADVANCED CONFIGURATION All of the following pages address advanced configuration of your IntelliScanner product, including how the scanner reads barcodes, the types of barcodes it will read, and how it enters text into your apps. IntelliScanner comes pre-configured to work for most situations.
-
Page 15: General Controls
GENERAL CONTROLS BEEPER... -
Page 16: Timeout/Reading Mode
POWER OFF TIMEOUT The timeout before automatic power off to save power. - Page 17 BUTTON MODE Choose how the button works, or enable continuious scanning (uses more battery).
-
Page 18: Keyboard Layout
KEYBOARD LAYOUT... - Page 19 IntelliScanner emulates a keyboard. If you’re using a keyboard layout other than the default, select it here.
- Page 20 KEYBOARD LAYOUT...
-
Page 22: Symbologies
ENABLE SYMBOLOGIES... - Page 23 IntelliScanner ships with a default set of common barcode symbologies enabled. Enable additional barcode types here for special applications.
- Page 24 END OF SCAN CHARACTER Sets the key that’s entered after each scan. The return key (CR) is the default; choose tab or another specialized key depending on your application.
-
Page 26: Upc/Ean/Isbn Advanced Controls
UPC/EAN/ISBN ADVANCED CONTROLS UPC-A EXPAND TO EAN-13 INCLUDE UPC 5-DIGIT ADD-ONS INCLUDE EAN-13 / ISBN 5 DIGIT ADD-ONS . H025$ . H026$ + 5 ON + 5 OFF... - Page 27 You will need it, along with a Return Authorization Number (RMA) for any warranty service. In order to keep the Warranty in effect for the IntelliScanner, the IntelliScanner must have been handled and used as prescribed in the instructions included with the IntelliScanner. THIS WARRANTY DOES NOT COVER ANY DAMAGE DUE TO ACCIDENT, MISUSE, ABUSE, OR NEGLIGENCE.
