INSTALLATION GUIDE
This guide helps you to operate AirScrape in a safe and effective way.
Familiarise yourself with the contents of this guide before you install the product and
start using it.
Pay particular attention to the warning instructions given in this guide. Failure to
observe these instructions entail the risk of serious injury and damage.
Do not attempt to commission the device if you do not understand the instructions
provided.
Inform your supervisor or safety officer.
To avoid damage and injuries, the Contact Free Conveyor Belt Skirting "AirScrape"
may be used for its intended purpose only to avoid damage and injuries.
All necessary measurements must be implemented by trained personnel only. The
owner is responsible for compliance with applicable regulations and provisions at
the location of use.
Contact Free
Conveyor Belt Skirting
Important Safety Information:
®
1
Advertisement
Table of Contents
Summary of Contents for ScrapeTec AirScrape
- Page 1 Conveyor Belt Skirting INSTALLATION GUIDE Important Safety Information: This guide helps you to operate AirScrape in a safe and effective way. Familiarise yourself with the contents of this guide before you install the product and start using it. Pay particular attention to the warning instructions given in this guide. Failure to observe these instructions entail the risk of serious injury and damage.
- Page 2 Intended use General use AirScrape is a Contact Free Conveyor Belt Skirting system which hovers freely above the conveyor belt, eliminating skirt friction and belt damage. Its unique array of inward facing hardened steel diagonal blades, deflects larger particles inwards...
- Page 3 Contents x AirScrape - left & right lenght: 2 m each inkl. lifting elements x Distance sheet 14 x Bolts weld on 14 x Nuts 14 x Washers x Installation guide and data sheet Prepare AirScrape for installation Adjust the angle of the AirScrape...
- Page 4 AirScrape and move the force distance metal sheet under the first bold of the AirScrape. Move the AirScrape up or down using the long holes so that the lamellas just touching the sheet. Tighten up the dome nut to get the AirScrape into the final position.
- Page 5 Check the tension of the lifting elements The distance holder sheet needs to be movable without force between belt and AirScrape ScrapeTec Trading GmbH | Rheinberger Straße 157 | 47475 Kamp-Lintfort, Germany Phone +49 2842 9 32 92 94 | info@scrapetec-trading.com | scrapetec-trading.com ASMONT1807V07EN...
