Full of Energy Y22H User Manual

Power bank
User manual
Product features
Charge your phone, tablet or other mobile
Ÿ
device without the need for a power outlet
Pocket-size design is perfect for portable
Ÿ
use
USB port provides up to 5V, 1A-2.1A of power
Ÿ
for charging your mobile devices
Battery-power LED indicator shows when
Ÿ
the battery is full or getting low
Protection features: short circuit, over-
Ÿ
voltage, over-current, over-charge and over-
discharge protection for safe and reliable
charging
Product specifications
Input 5V, 1A
Output 5V, 1A/2.1A
Ripple And Noise
≤180mVp-p
Operating Temperature Range 32° to 113°F (0° to 45°C)
Storage Temperature Range
5° to 140°F (-15° to 60°C)
Over-current Protection Yes
Over-voltage Protection Yes
Over-charge Protection
Yes
Over-discharge Protection
Yes
Short Circuit Protection Yes
E ciency
≥ 79.28%
Power bank charging
Using the included USB Micro-B cable, connect
Ÿ
the Micro-B port located on the Mobile Power
Bank to the USB-A port on a computer or USB
Charger
The Mobile Power Bank will begin charging with
Ÿ
the LED indicator light illuminating
Charge status LED 1 LED 2 LED 3 LED 4
0% - 25%
25% - 50%
50% - 75%
75% - 100%
Finished
Error detected
Digital products charging
Connect your mobile device to the USB-A port
Ÿ
on the Mobile Power Bank using the included
USB Micro-B cable or a USB cable suitable for
your device
The device will begin charging with the LED
Ÿ
indicator light illuminating
Charge status LED 1 LED 2 LED 3 LED 4
75% - 100%
50% - 75%
25% - 50%
5% - 25%
< 5%
0%
Error detected
Product specifications
