Summary of Contents for SGM Displayer 250
- Page 1 Displayer graphic projector rel. 1.03 user manual Displayer g r a p h i c p r o j e c t o r...
-
Page 2: General Warnings
• If you spill water on the unit be very careful, as a fire could break out or there could be a dangerous shock. Immediately disconnect the main power and contact the nearest SGM dealer. • In the event of serious operating problems, stop using the unit immediately and either contact the nearest SGM sales point for a check, or contact the manufacturer directly. -
Page 3: Table Of Contents
Dynamic mode - Colours Dynamic mode - Images Dynamic mode - Prism Dynamic mode - Dimmer Example of use in static mode Example of use in dynamic mode Made in Italy by SGM Electronic Printed in September 1998 • Rel. 1.03 appendice... -
Page 4: General Features
General features The Displayer 250 graphic projector is a result of the cutting edge design policy which all SGM pro- ducts have had in common for years and has been expressly built for projecting logos, information and publicity. Like every SGM product, it passed the firm’s long trail period and strict tests brilliantly before being put on the market, ensuring high quality and reliability up to customary SGM standards. -
Page 5: Positioning And Focussing
Positioning and focussing To position the projector, switch it on, set it in the required position by turning it on the support bracket, then lock it in place with the knobs on the bracket. Focussing the Displayer is very easy, fast and really precise, using the Focus screw knob on the front of the projector. -
Page 6: Access And Maintenance
Access and Maintenance Displayer has a very unusual system for access to the inside of the projector. Although being left han- ging in the position it’s installed in, the projector can be opened in half length-wise, thus enabling extremely easy access to the components inside to carry out any necessary work (cleaning, relamping or maintenance work on any mechanical or electronic parts, etc.). -
Page 7: Cleaning The Projector
Cleaning the projector Clean optics - inside and out - are decisive for luminous output and this work must be carried out periodically. The regularity with which cleaning is done depends above all on the surroundings in which the fixture is used: in particular, damp, very smoky or dusty surroundings cause dirt to build up on the fixture’s optics. -
Page 8: Displayer 250 Functions
Displayer 250 functions The Displayer 250 was designed and built for projecting logos and publicity images. It was therefore intended for use in every possible situation. Its functions are divided into two main groups: static and dynamic. Static use is when the Displayer projects a single image, e.g. an arrow indicating an exit. - Page 9 Static mode - Colour The following table shows the settings for controlling the colors in Static mode. 1 2 3 4 5 6 7 8 9 1 2 3 4 "Rainbow" Effect 1 2 3 4 5 6 7 8 9 1 2 3 4 White 1 2 3 4 5 6 7 8 9...
-
Page 10: Static Mode - Images
Static mode - Images The following table shows the settings for controlling the images in Static mode. Images 1, 3, 5 and 7 don’t have rotary mechanism. 1 2 3 4 5 6 7 8 9 1 2 3 4 Image 1 non rotating 1 2 3 4 5 6 7 8 9 1 2 3 4... -
Page 11: Dynamic Mode - Colours
Dynamic mode - Colours The following table shows the settings for controlling the colors in Dynamic mode. 1 2 3 4 5 6 7 8 9 1 2 3 4 "Rainbow" Effect 1 2 3 4 5 6 7 8 9 1 2 3 4 White fix 1 2 3 4 5 6 7 8 9... -
Page 12: Dynamic Mode - Images
Dynamic Mode - Images The following table shows the settings for controlling the images in Dynamic mode. 1 2 3 4 5 6 7 8 9 1 2 3 4 Fixed image 1 2 3 4 5 6 7 8 9 1 2 3 4 Image changing every 10sec. -
Page 13: Example Of Use In Static Mode
Example of use in static mode 1 2 3 4 5 6 7 8 9 1 2 3 4 The above example shows the setting for using the Displayer in static mode. In this mode only image N°1 is projected, the colour is white and there’s a 45 second dimmer sweep. Example of use in dynamic mode 1 2 3 4 5 6 7 8 9 1 2 3 4... - Page 14 Via Pio La Torre, 1 • 61010 TAVULLIA (PS) • ITALY • Tel. +39 0721476477 • Fax +39 0721476170 www.sgm.it • info@sgm.it...
