ComAp InteliPro Comprehensive Manual

Protection relay for parallel applications
Hide thumbs Also See for InteliPro:
Table of Contents

Advertisement

Quick Links

See also: Operation & Installation Manual
InteliPro
Protection Relay for Parallel Applications
Comprehensive Guide - rev. 1
SW version 1.0, May 2011
Copyright © 2011 ComAp s.r.o.
Written by Tomas Jelen
Prague, Czech Republic
Installation and Operation Guide
Communication Brochure
ComAp, spol. s r.o.
Kundratka
2359/17, 180 00 Praha 8, Czech Republic
Tel: +420
246 012
111, Fax: +420 246 316 647
E-mail: info@comap.cz, www.comap.cz
Application Guide
Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InteliPro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ComAp InteliPro

Summary of Contents for ComAp InteliPro

  • Page 1 SW version 1.0, May 2011 Installation and Operation Guide Application Guide Communication Brochure Reference Guide ComAp, spol. s r.o. Copyright © 2011 ComAp s.r.o. Kundratka 2359/17, 180 00 Praha 8, Czech Republic Written by Tomas Jelen Tel: +420 246 012...
  • Page 2 Though InteliPro is very simple and intuitive for the operating personnel, we recommend to keep one copy of this manual available permanently at the installation site, where InteliPro unit is installed, to facilitate the necessary service and operation tasks.
  • Page 3 Protection Relay for Parallel Applications Installation and Operation Guide SW version 1.0, May 2011 Installation and Operation Guide ComAp, spol. s r.o. Copyright © 2011 ComAp s.r.o. Kundratka 2359/17, 180 00 Praha 8, Czech Republic Written by Tomas Jelen Tel: +420...

  • Page 4: Table Of Contents

    Recommended wiring ........................10 Configurability............................ 11 Options system ..........................13 User Interface ............................15 Control and navigation Pushbuttons - basic operation ..............15 Sinalization LEDs ..........................15 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...

  • Page 5: Introduction

    To avoid personal injury do not perform any action not specified in this guide!!! Note: ComAp believes that all information provided herein is correct and reliable and reserves the right to update at any time. ComAp does not assume any responsibility for its use unless otherwise expressly undertaken.

  • Page 6: Installation Data

    The unit is to be mounted onto the switchboard door. Requested cutout size is 175x115mm. Use the screw holders delivered with the unit to fix the controller into the door as described on pictures below. InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...

  • Page 7: Terminal Diagram

    Settings group. Learn about how to view and change setpoints in the User interface chapter. OLTAGE MEASUREMENT WIRING <Comm Trp> / <Trip 1> / <Trip 2> MAINS VOLTAGE InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...
  • Page 8 <Trip 1> / <Trip 2> MAINS VOLTAGE URRENT MEASUREMENT WIRING <Comm Trp> / <Trip 1> / <Trip 2> MAINS CURRENT HECK WIRING L2/N SYNC MAINS CHECK VOLTAGE InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...

  • Page 9: Binary Inputs

    (signalization etc..). The function of each output has to be assigned during the configuration. AUTION Use suppression diodes on all relays and other inductive loads! InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...

  • Page 10: Analog Inputs

    The fail sensor alarm is issued if the measured resistance is smaller than one half of the first (lowest) point of the sensor curve characteristic or is greater than 112,5% of the last (greatest) point of the sensor curve characteristic. InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...

  • Page 11: Tristate Inputs

    The threshold level is 750Ω. In case of tristate, values lower than 10Ω and values over 2400Ω are evaluated as sensor failure (short or open circuit). InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Installation and Operation Guide...

  • Page 12: Recommended Wiring

    The name, sensor characteristic and alarm types for each analog input have to be assigned during the configuration. Recommended wiring In the diagram below, see the typical wiring of the InteliPro unit inputs and outputs. The wiring is to be considered as an example for the default configuration and operation mode with 1 common trip output.

  • Page 13: Configurability

    Configurability One of the key features of InteliPro unit is high level of flexibility and adaptability of the system to the particular application. The way how to achieve this is the configuration. Use LiteEdit PC software to read the configuration from the controller or disk, view it, modify it and write the configuration to controller or disk.
  • Page 14 The archive can be simply used for cloning of InteliPro units, which means preparing units with identical configuration and settings.

  • Page 15: Options System

    IPro-81R Rate of change of frequency + rocof filter The appropriate selection of InteliPro optional functions is to be marked on the rear side of the unit: For unlocking the desired functions or changing those functions that are already unlocked, contact your sales person for the appropriate SW dongle.
  • Page 16 Settings: Dongle and enter the numerical string, which you have obtained. Though it is more convenient to enter the SW dongle via LiteEdit PC software, it is also possible to enter it through the controller screen and pushbuttons. InteliPro, SW version 1.0, ©ComAp – May 2011 1-14 InteliPro Installation and Operation Guide...

  • Page 17: User Interface

    It is possible to change only passwords of the same or lower level than actually entered password! Sinalization LEDs There are 5 LEDs for indication of InteliPro status with the meaning indicated in the table below: InteliPro, SW version 1.0, ©ComAp – May 2011...
  • Page 18 Meaning Status of the InteliPro unit - used in combination with green LED, see the table below (red) Status of the InteliPro unit - used in combination with red LED, see the table below (green) CB1 feedback - activated - state "I"...
  • Page 19 InteliPro Protection Relay for Parallel Applications Application Guide SW version 1.0, May 2011 Application Guide ComAp, spol. s r.o. Copyright © 2011 ComAp s.r.o. Kundratka 2359/17, 180 00 Praha 8, Czech Republic Written by Tomas Jelen Tel: +420 246 012...
  • Page 20 Directional overcurrent (DOC, ANSI 67)..................11 Neutral Voltage Displacement (NVD, ANSI 59N) ................. 12 Directional power (ANSI 32) ......................12 Synchro check (ANSI 25) ......................13 AC reclosing (ANSI 79)......................... 13 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Application Guide...

  • Page 21: Introduction

    In any case, it must be assured that the InteliPro relay has full control at opening the appropriate breaker by the trip command - i.e. in case of Trip state the unit receives the appropriate CB feedback, confirming its open position.

  • Page 22: Operation Mode With 2 Trip Outputs

    2 are available. • For each protective function in InteliPro, it is possible to assign either Trip 1 or Trip 2 function, none of them, or both. The setpoint xxx Trp BO in the appropriate group of protection setting is used for this assignment.

  • Page 23: Trip And Fault Reset Description

    The function is compatible with IG/IS-NT controllers. CAN2 interconnection between the gen-set controllers and InteliPro is necessary to allow this feature. Use the LiteEdit configuration window to configure the appropriate binary and analog values to be transmitted from InteliPro via the CAN2 button.
  • Page 24 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Application Guide...

  • Page 25: Protective Functions

    In order to e.g. activate only one adjustable pickup used within a multiple-stages protective function, set this pickup limit to zero. E.g. InteliPro allows setting 2 stages of overvoltage protection. To use only V> and block the V>> stage, set the pickup limit V>> to 0V. In general, setting of any pickup limit of any protective function blocks this protection stage.

  • Page 26: Protective Functions In Detail

    V Unb: V Unb. It refers to the amplitude unbalance of the measured voltage. "Loss of mains" protections InteliPro provides two different methods for fast evaluation of loss of mains (LOM), into which the generator operates: Vector shift Rate Of Change Of Frequency The loss-of-mains protections setting is done using the setpoints in the group LOM.

  • Page 27: Rate Of Change Of Frequency (Df/Dt, Rocof, Ansi 81R)

    (loss of mains), which is normally capable of keeping the frequency on a stable level. The frequency change is expressed as tangent in time [Hz/s]: InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Application Guide...

  • Page 28: Overcurrent: Definite-Time, Idmt And With Voltage Control

    It is a fast protection, similar to Vector shift, however, unlike Vector shift, which detects immediate phenomena, the tangent calculation requires a certain time for evaluation. In ComAp protection relays, the evaluation time for ROCOF protection can be adjusted in number of sine curve cycles being taken into evaluation from 1 to tens of cycles (each having 20ms).
  • Page 29 Compared to the "reverse power protection", DOC protection detects also reactive currents from the given angle zone, what allows better sensitivity for tripping. InteliPro, SW version 1.0, ©ComAp – May 2011 2-11 InteliPro Application Guide...
  • Page 30 The following image shows the conditions of activation of Directional Overcurrent protection in InteliPro – i.e. critical angles between voltage and current, given the voltage is placed at the 0°angle: 90° 150° 0° DOC> Base angle Trip area -135° -60°...
  • Page 31 In InteliPro, either L1-L2 phase-to-phase voltage or L1- N phase-to-neutral voltage is measured on the generator side of the circuit breaker and compared with the corresponding measured mains voltage.
  • Page 32 InteliPro Protection Relay for Parallel Applications Application Guide SW version 1.0, May 2011 Communication Brochure ComAp, spol. s r.o. Copyright © 2011 ComAp s.r.o. Kundratka 2359/17, 180 00 Praha 8, Czech Republic Written by Tomas Jelen Tel: +420 246 012...
  • Page 33 CAN bus and RS485 ..........................2 Recommended CAN/RS485 connection..................... 4 CAN bus connection ........................4 RS485 connection........................... 4 Communication modules ......................... 6 IL-NT-232 ............................6 IL-NT-RS232-485..........................6 IL-NT-S-USB ............................7 IB-Lite ..............................7 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Communication Brochure...

  • Page 34: Can Bus And Rs485

    Use cable with following parameters: Cable type Shielded twisted pair Impedance 120Ω Propagation velocity >= 75% (delay <= 4.4 ns/m) Wire crosscut >= 0.25mm Attenuation (@1MHz) <= 2dB/100m BUS TOPOLOGY InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Communication Brochure...

  • Page 35: Recommended Can/Rs485 Connection

    1. For shorter distances: 3105A Paired - EIA Industrial RS-485 PLTC/CM (1x2 conductors) 2. For shorter distances: 3105A Paired - EIA Industrial RS-485 PLTC/CM (1x2 conductors) 3. In case of surge hazard: 3106A Paired - EIA Industrial RS-485 PLTC/CM (1x2+1 conductors) InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Communication Brochure...
  • Page 36 SHORTER DISTANCES ALL NETWORK COMPONENTS WITHIN ONE ROOM ICTURE LONGER DISTANCES CONNECTION BETWEEN ROOMS WITHIN ONE BUILDING ICTURE SURGE HAZARD CONNECTION OUT OF BUILDING IN CASE OF STORM ETC InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Communication Brochure...

  • Page 37: Communication Modules

    Communication module enables connection of a remote computer or other remote device such as PLC to InteliPro. The module is to be plugged-in into the slot in the rear side of InteliPro. The slot is accessible after slot cover is removed.

  • Page 38: Il-Nt-S-Usb

    IB-Lite is a plug-in module with Ethernet 10/100 Mbit interface in RJ45 connector. The module is internally connected to both COM1 and COM2 serial channels and provides an interface for InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Communication Brochure...
  • Page 39 The module can be also connected directly to a PC using cross-wired UTP cable. ROSS WIRED CABLE For more detail about communication of ComAp products, see the IL-NT, IA-NT, IC-NT Communication Guide as published on ComAp download centre. InteliPro, SW version 1.0, ©ComAp – May 2011...
  • Page 40 InteliPro Protection Relay for Parallel Applications Reference Guide SW version 1.0, May 2011 Reference Guide ComAp, spol. s r.o. Copyright © 2011 ComAp s.r.o. Kundratka 2359/17, 180 00 Praha 8, Czech Republic Written by Tomas Jelen Tel: +420 246 012...
  • Page 41 I Unb Sig ............................12 DOC Sig............................12 DOC Test ............................12 EFC Sig............................12 IGS Sig............................12 NVD Sig ............................12 P Sig ............................. 13 Sync Check........................... 13 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 42 ShTermPar Prot [ENABLED / DISABLED]................20 Prio Switching [ DISABLED / CB1 -> CB2 / CB1 <- CB2 / CB1 <-> CB2 ] ....... 20 IPro-SW Key ..........................20 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 43 [ Block 1 / Block 2 / Block 1+2 / None ] .............. 27 DOC Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ]................. 27 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 44 [ s ] ............33 IOM AI1 BlockBI, IOM AI2 BlockBI, IOM AI3 BlockBI, IOM AI4 BlockBI [ Block 1 / Block 2 / Block 1+2 / None ] InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 45 Mains measurements ........................36 Remote communication interface ....................36 Extesion modules interface......................36 Interface to other controllers ......................37 Relay Card CT2-REL2 ........................37 Recommended CAN cables ......................37 InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 46 Only Comm Trp output is activated in case of binary alarm Trp 1 Trp 1 output is activated in case of binary alarm Trp 2 Trp 2 output is activated in case of binary alarm InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 47 CommTrp and Trp 1 activation. If it is configured in the unit and it does not open, CB1 fail is indicated. In general, this breaker corresponds to the "Mains Circuit Breaker" = MCB in the ComAp controllers applications. Together with CB2 it indicates, whether the installation is in "parallel to mains" state (both CB1 Feedback and CB2 Feedback are closed) or in island mode (one or both of CB1 Feedback or CB2 Feedback are open).
  • Page 48 Trp 1 Trip output assignable to different protection stages by setpoint xxx Trp BO (e.g. V Trp BO). It activates whenever any assigned protection trips. It resets automatically when AutoFaultReset InteliPro, SW version 1.0, ©ComAp – May 2011 InteliPro Reference Guide...
  • Page 49 (underfrequency, overfrequency) is active or not acknowledged by Fault Reset. V Unb Protection Separate output for voltage unbalance protection. PhaseRot Prot Separate output for phase sequence protection. VectorS Prot Separate output for vector shift protection. InteliPro, SW version 1.0, ©ComAp – May 2011 4-10 InteliPro Reference Guide...

  • Page 50: Neutral Overcurrent (Ansi 50N, Ansi 51N)

    Deactivates in the moment when the measured values are back in limits. Fault reset has no effect on this output. f Sig Signalling output of "out of limit" frequency according to the setting in f<> group. InteliPro, SW version 1.0, ©ComAp – May 2011 4-11 InteliPro Reference Guide...

  • Page 51: Neutral Voltage Displacement (Nvd, Ansi 59N)

    (does not wait until delay times out). Deactivates in the moment when the measured values are back in limits. Fault reset has no effect on this output. InteliPro, SW version 1.0, ©ComAp – May 2011 4-12...

  • Page 52: Synchro Check (Ansi 25)

    AL AIx Wrn/Trp, AL IOM AIx Wrn/Trp The outputs are available to indicate warning or trip, caused by any of the analog inputs on InteliPro unit, or on IOM extension module, where "x" marks the number of the analog input. The output is activated in the moment when the appropriate AI warning/trip event is issued and stays activated until the alarm message disappears from the alarm list.
  • Page 53 The output activates in case of any sensor-fail on the analog inputs. BIx Status, IOM BIx Status The outputs correspond to the status of the physical inputs of the unit or the IG-IOM or IGS-PTM extension module respectively. InteliPro, SW version 1.0, ©ComAp – May 2011 4-14 InteliPro Reference Guide...
  • Page 54 See also LiteEdit help to learn about working with password in LiteEdit. Basic Settings ControllerName User defined name, used for InteliPro identification. ControllerName is max 14 characters long and has to be entered manually using LiteEdit software. Default setting: InteliPro Mains CT Ratio [A/5A] Mains current transformers ratio.
  • Page 55 0 = OFF, CB2 protection function is disabled Default setting: 0 s Comms Settings Contr. Addr Unit identification address number. In case of connection to CAN bus together with other ComAp controllers, different address than that of the controllers has to be entered. Range: 1 - 32...
  • Page 56 Adjusting of the speed of Modbus communication Default setting: 9600 bps CAN Bus Mode [ 32C / 8C ] CAN bus speed selection. Use this setpoint in case that you operate InteliPro together with other ComAp contollers connected via CAN bus. 32C: High speed CAN (250 kbps) applicable up to 32 controllers, CAN bus length limited up to 200 meters.
  • Page 57 [ s ] Common delay for all protections to activate after CB2 FEEDBACK, CB1 FEEDBACK inputs are closed. Step: 0,1s Range: 0 – 30 s Default setting: 2,0 s InteliPro, SW version 1.0, ©ComAp – May 2011 4-18 InteliPro Reference Guide...
  • Page 58 CB1 Feedback and CB2 Feedback binary inputs are active and the assigned blocking input is not active (or there is no blocking input assigned) InteliPro, SW version 1.0, ©ComAp – May 2011 4-19 InteliPro Reference Guide...
  • Page 59 This setpoint is not overwritten after FW upgrade. The setpoint is not visible on InteliPro display in reading mode to avoid confusion of the user. It is possible to edit this setpoint through InteliPro display and pushbuttons - in this mode it becomes visible. It is however advisable to use LiteEdit for filling-in the SW Key.
  • Page 60 Default setting: 5,00 s V Unb Block BI [ Block 1 / Block 2 / Block 1+2 / None ] Selection of blocking binary input for voltage asymmetry protection. InteliPro, SW version 1.0, ©ComAp – May 2011 4-21 InteliPro Reference Guide...
  • Page 61 Default setting: None f Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ] Selection of trip binary output for frequency protections. Default setting: None InteliPro, SW version 1.0, ©ComAp – May 2011 4-22 InteliPro Reference Guide...
  • Page 62 Selection of trip binary output for loss of mains protections. Default setting: None I> NominMainsCurr [ A ] Nominal mains feeder current. Serves for Ishort and Earth Fault current protections’ evaluation. Step: InteliPro, SW version 1.0, ©ComAp – May 2011 4-23 InteliPro Reference Guide...
  • Page 63 I> T Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ] Selection of trip binary output for time overcurrent protection. Default setting: None InteliPro, SW version 1.0, ©ComAp – May 2011 4-24 InteliPro Reference Guide...
  • Page 64 Threshold of current unballance protection. Protection is evaluated as maximum difference between any of the phase currents and the average value of phase currents. Step: Range: 0 - 200 % Default setting: 50 % InteliPro, SW version 1.0, ©ComAp – May 2011 4-25 InteliPro Reference Guide...
  • Page 65 [ Trp 1 / Trp 2 / Trp 1+2 / None ] Selection of trip binary output for current unballance protection. Default setting: None NominGenCurr [ A ] Nominal current of the generator(s) connected to the mains feeder, protected by the InteliPro unit. Serves for directional overcurrent protection evaluation. Step: Range:...
  • Page 66 ANSI standard IECInv: moderately inverse curve according to IEC standard IECVerInv: very inverse curve according to IEC standard IECExtInv: extremely inverse curve according to ANSI standard Default setting: IDMT InteliPro, SW version 1.0, ©ComAp – May 2011 4-27 InteliPro Reference Guide...
  • Page 67 IGS Block BI [ Block 1 / Block 2 / Block 1+2 / None ] Selection of blocking binary input for ground surge overcurrent protection. Default setting: None InteliPro, SW version 1.0, ©ComAp – May 2011 4-28 InteliPro Reference Guide...
  • Page 68 Default setting: OVER P Block BI [ Block 1 / Block 2 / Block 1+2 / None ] Selection of blocking binary input for directional power protection. InteliPro, SW version 1.0, ©ComAp – May 2011 4-29 InteliPro Reference Guide...
  • Page 69 Enabling/disabling the synchro-check function of closing "dead" mains to "hot" bus. ENABLED: situation of dead mains (mains voltage below Dead V Lim) and live bus (Sync Check voltage within limits) is considered as "synchronous" state InteliPro, SW version 1.0, ©ComAp – May 2011 4-30 InteliPro Reference Guide...
  • Page 70 When the synchronous conditions are met, the deactivation of the trip output is no longer blocked. InteliPro, SW version 1.0, ©ComAp – May 2011 4-31 InteliPro Reference Guide...
  • Page 71 Delay of protections assigned to analog input 1, 2 or 3 of the unit respectively. It is the same for warning alarm and trip. Step: Range: 0 - 600 s Default setting: 5 s InteliPro, SW version 1.0, ©ComAp – May 2011 4-32 InteliPro Reference Guide...

  • Page 72: Sms/E-Mail

    Default setting: OFF TelNo/Addr Ch1, TelNo/Addr Ch2 2 possibilities of enetring phone number or e-mail to which the message will be sent in case that warning or trip occurs. InteliPro, SW version 1.0, ©ComAp – May 2011 4-33 InteliPro Reference Guide...

  • Page 73: Date/Time

    (summer) season. WINTER-S (SUMMER-S): Modification for southern hemisphere. Default setting: DISABLED Note: In case of interconnection of InteliPro with other ComAp units on the CAN2 bus, the setpoint is automatically synchronized within the interconnected group. #Time [HHMMSS] Real time clock adjustment.

  • Page 74: Technical Data

    5-25Hz, +/- 1.6mm; 25-100Hz, a = 4g Shocks 200m/s Storage temperature -30... 80°C InteliPro is intended for use with switchgear and Intended use according to associated equipment as per the category for Protective relays – UL 508 standard NRGU Physical dimensions...

  • Page 75: Binary Outputs

    Depending on selected mode (up to 57600 bps) Optional using the plug-in module IL-NT-S-USB Ethernet Optional using the plug-in module IB-Lite Extesion modules interface Type CAN bus Galvanic insulation Insulated, 500V InteliPro, SW version 1.0, ©ComAp – May 2011 4-36 InteliPro Reference Guide...

  • Page 76: Interface To Other Controllers

    Baud rate 250kbps Bus length max. 200m Termination resistor 120Ohm, built-in, jumper activated Relay Card CT2-REL2 The module is delivered as a default part of the InteliPro unit. Relay contacts Number of relay outputs Type Dry contacts Operating voltage 250 VAC...
