Toolex 592720 Instruction Manual

Demolition jack hammer
Hide thumbs

Advertisement

Quick Links

Download this manual
592720
DEMOLITION
JACK HAMMER
BEFORE USING THIS TOOLEX DEMOLITION HAMMER, PLEASE CAREFULLY
READ THOUGH THESE HANDLING INSTRUCTIONS. ENSURE THAT YOU KNOW
HOW THE MACHINE WORKS, AND HOW IT SHOULD BE OPERATED. MAINTAIN
THE MACHINE IN ACCORDANCE WITH THE INSTRUCTIONS, AND MAKE CERTAIN
THAT THE MACHINE WORKS CORRECTLY, PLEASE STORE THIS INSTRUCTIONS
AND OTHER ENCLOSED DOCUMENTS WITH THE MACHINE TOGETHER.
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the 592720 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toolex 592720

  • Page 1 592720 DEMOLITION JACK HAMMER BEFORE USING THIS TOOLEX DEMOLITION HAMMER, PLEASE CAREFULLY READ THOUGH THESE HANDLING INSTRUCTIONS. ENSURE THAT YOU KNOW HOW THE MACHINE WORKS, AND HOW IT SHOULD BE OPERATED. MAINTAIN THE MACHINE IN ACCORDANCE WITH THE INSTRUCTIONS, AND MAKE CERTAIN THAT THE MACHINE WORKS CORRECTLY, PLEASE STORE THIS INSTRUCTIONS AND OTHER ENCLOSED DOCUMENTS WITH THE MACHINE TOGETHER.

  • Page 2: Table Of Contents

    Contents 1. Machine information 2. Safety instruction 3. Assembly 4. Operation 5. Maintenance 6. Warranty 7. Environment 1. Machine information Technical specifications Machine Type 592720 Voltage AC 230V Frequency 50Hz Input power 1500W Impact rate 1400/min Weight 16.86kg Impact energy...
  • Page 3 Standard accessories Hexagon bar wrench 6mm(for M8) 1 piece Hexagon bar wrench 5mm(for M6) 1 piece Oil tank cover wrench 1 piece One bottle of oil 60g (one bottle) Bull point chisel(30*410mm) 1 piece flat chisel(30*410mm) 1 piece Carbon brush(7*17*18mm) 2 pieces Optional accessories (sold separately）...
  • Page 4 6. Tine spade Hexagon size30*440 length (Unit: mm) 7. Square spade Hexagon size30*440 length (Unit: mm) 8. Bush hammer heads + Shank Hexagon size30*410 length (Unit: mm) Tooth distance: 12mm Tooth high: 8mm Length*width: 60*60mm 9. Tamping plate + Shank Hexagon size30*394 length (Unit: mm) Length*width: 150*150mm 10.

  • Page 5: Safety Instruction

    12. 4PCS KITS Hexagon size30*410 length (Unit: mm) 2. Safety instructions In this operator's manual/or machine’s labels following symbols are used: Read the manual carefully Accordance with essential applicable safety of European directives Doppelt isoliert Denote risk of personal injury, loss of life or damage to the tool in case of nonobservance of the instruction in this manual.
  • Page 6 Faulty and /or discarded electrical or electronic apparatus have to be collected at the appropriate recycling location. The guaranteed Noise Value according to Noise Directive General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury.
  • Page 7 e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tools in a damp location is unavoidable, use a residual current device (RCD) protected supply.
  • Page 8 e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. f) Keep cutting tools sharp and clean.

  • Page 9: Assembly

    9、Don't point the tool to anybody for the bit could fly out in case. 10、When chipping into walls, floors or wherever "live" electrical wire may be encountered, DON'T TOUCH ANY METAL PARTS OF THE TOOL! Hold the tool by the insulated grasping surface to prevent electric shock if you chip into a "live"...
  • Page 10 Mounting tool bits Warning: before do it, make sure unplug the machine! (1) Pull out of the retainer "2", turning 180℃ clockwise or anticlockwise, insert the accessory shank portion"1" into the hole on the front cover. (2) Turning the retainer back into original position. Remarking: When you removing the accessory, such as a bull point, a cutter etc.., follow above procedure in reverse order.

  • Page 11: Operation

    4. Operation Prior to operation 1. Power source Ensure that the power source to be utilized conforms to the power requirements which specified on the name plate of the hammer. 2. Power switch Ensure that the power switch is in the position of OFF. If the plug is connected to power receptacle while the power switch is in ON position, the demolition hammer will start operation immediately, which can cause serious accident! Operation...

  • Page 12: Warranty

    4. Following above describe, after that make sure tighten the oil hole plug and clean the machine. Maintenance and inspection Before do any maintenance, ensure unplug the plug. 1. Inspecting the demolition hammer Use a dull accessory, such as bull point, cutter, etc., will cause motor malfunction and efficiency degraded.
  • Page 13 In case of alternation of the machine, not agreed upon by us, this declareation will lose its validity. Machine Description: Demolition Hammer Machine Type: 592720 Applicable EC Directive: EC Machinery Directive (98/37/EC) EC Low Voltage Directive (2006/95/EC)
  • Page 14 592720 Hammer Part Chart Page 14...
  • Page 15 592720 Hammer Parts List Page 15...
